This page will show general information, such as name, group, IP address, MAC address,
model and password of VigorSwitch only when it connects to Vigor2926 series. By clicking the
index number link, a profile setting page for that switch will be shown. Note that each profile
represents one VigorSwitch.
Available settings are explained as follows:
Item
Index
Name
Group
IP Address
MAC Address
Model
Password
Delete Profile
To edit profile for the selected switch:
1. Click index number link (e.g. #1) to open the following page.
Available settings are explained as follows:
580
r o f i l e
r o f i l e
Description
Click the number link to access into the switch profile.
Note: Each connected VigorSwitch will have one setting
profile. If there are many switches connected to Vigor2926,
different index number will be used to represent different
VigorSwitch.
Display the user defined name of VigorSwitch.
Display the group name of VigorSwitch(es).
Display the IP address of VigorSwitch.
Display the MAC address of VigorSwitch.
Display the model name of VigorSwitch.
Click it to display the account information including
username and password.
Click the mark of "X" to delete the switch profile.
