I-1-1 Indicators And Connectors; I-1-1-1 For Vigor2926 / Vigor2926L - Draytek Vigor2926L User Manual

I - 1 - 1 I n d
I - 1 - 1 I n d
Before you use the Vigor router, please get acquainted with the LED indicators and
connectors first.
I - 1 - 1 - 1 F o
I - 1 - 1 - 1 F o
LED
ACT (Activity)
WAN1~WAN2
QoS
LTE
USB1~USB2/
USB
WCF
VPN
DMZ
LED on Connector
LAN1~LAN4
WAN1~
WAN2
2
i c a t o r s a n d C o n n
i c a t o r s a n d C o n n
r V i g o r 2 9 2 6 / V i g o r
r V i g o r 2 9 2 6 / V i g o r
Status
Blinking
Off
On
Off
Blinking
On
On
Off
Blinking
On
Blinking
On
On
Off
Blinking
On
Off
Blinking
Left On
LED
Off
Blinking
Right On
LED
Off
Left On
LED
Off
Blinking
Right On
LED
Off
e c t o r s
e c t o r s
2 9 2 6 L
2 9 2 6 L
Explanation
The router is powered on and running normally.
The router is powered off.
Internet connection is ready.
Internet connection is not ready.
The data is transmitting.
The QoS function is active.
SIM card is connected and running normally.
LTE device is not detected or encounters troubles
(e.g., No SIM, SIM PIN error, SIM deactivated)
Quickly: The data is transmitting.
Slowly: LTE device is in dialing up procedure.
USB device is connected and ready for use.
The data is transmitting.
The Web Content Filter is active. (It is enabled from
Firewall >> General Setup).
The VPN tunnel is active.
VPN service is disabled.
Traffic is passing through VPN tunnel.
The DMZ function is enabled.
The DMZ function is disabled.
The data is transmitting.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps
Vigor2926 Series User's Guide
