Vii-2-2 Bandwidth Limit - Draytek Vigor2926L User Manual

V I I - 2 - 2 B
V I I - 2 - 2 B
In the Bandwidth Management menu, click Bandwidth Limit to open the web page.
To activate the function of limit bandwidth, simply click Enable and set the default upstream
and downstream limit.
Available settings are explained as follows:
Item
Enable
Disable
Limitation List
460
a n d w i d t h L i m i t
a n d w i d t h L i m i t
Description
Click this button to activate the function of limit bandwidth.
IP Routed Subnet – Check this box to apply the bandwidth
limit to the second subnet specified in LAN>>General Setup.
It is available for IPv4 settings only.
Default TX limit - Define the default speed of the upstream
for each computer in LAN.
Default RX limit - Define the default speed of the
downstream for each computer in LAN.
Click this button to close the function of limit bandwidth.
Display a list of specific limitations that you set on this web
page.
Vigor2926 Series User's Guide
