Vii-6-3 Wlan Profile - Draytek Vigor2926L User Manual

V I I - 6 - 3 W
V I I - 6 - 3 W
WLAN profile is used to apply to a selected access point. It is very convenient for the
administrator to configure the setting for access point without opening the web user interface
of the access point.
Click the number link of the selected profile to modify the content of the profile. Available
settings are explained as follows:
Item
Profile
Name
Main SSID
Security
Multi-SSID
WLAN ACL
Rate Ctrl
Clone
To AP
556
L A N P r o f i l e
L A N P r o f i l e
Description
Display the name of the profile.
The default profile cannot be renamed.
Display the name of the profile.
The default profile cannot be renamed.
Display the SSID configured by such wireless profile.
Display the security mode selected by such wireless profile.
Enable means multiple SSIDs (more than one) are active.
Disable means only SSID1 is active.
Display the name of the access control list.
Display the upload and/or download transmission rate.
It can copy settings from an existing WLAN profile to another
WLAN profile.
First, you have to check the box of the existing profile as the
original profile. Second, click Clone. The following dialog will
appear.
Third, choose the profile index to accept the settings from the
original profile. Forth, type a new name in the field of
Renamed as. Last, click Apply to save the settings on this
dialog.
The new profile has been created with the settings coming
from the original profile.
Click it to apply the selected wireless profile to the specified
Access Point.
Vigor2926 Series User's Guide
