Draytek Vigor2926L User Manual page 533

Enter Mobile
Number Description
Send Button
Description
Send Button Color
Send Succeeded
Message
Save and Next
Cancel
4 . W h i t e
4 . W h i t e
In this step you can configure the whitelist settings. Users are allowed to send and receive
traffic that satisfies whitelist settings.
Available settings are explained as follows:
Item
NAT Rules
Dest Domain
Dest IP
Dest Port
Source IP
Vigor2926 Series User's Guide
Enter message to be displayed in the mobile number textbox to
prompt the user to enter the mobile number.
Enter the label text of the send button.
Select the color of the send button from the predefined color list,
or select Customize Color and enter the RGB value. Click Preview
to preview the selected color.
Enter text to be displayed to notify the user after the PIN has been
sent.
Click to save the configuration on this page and proceed to the
next page.
Click to abort the configuration process and return to the profile
summary page.
l i s t S e t t i n g
l i s t S e t t i n g
Description
To prevent web portal settings from conflicting with NAT rules
resulting in unexpected behavior, select the NAT rules that are
allowed to bypass the web portal. Hosts listed in selected NAT
rules can always access the Internet without being intercepted by
the web portal.
Enter up to 30 destination domains that are allowed to be
accessed.
Enter up to 30 destination IP addresses that are allowed to be
accessed.
Enter up to 30 destination protocols and ports that are allowed
through the router.
Enter up to 30 source IP addresses that are allowed through the
router.
517
