Action
How Often
Cycle duration
3. Click OK button to save the settings.
Example
Suppose you want to control the PPPoE Internet access connection to be always on (Force On)
from 9:00 to 18:00 for whole week. Other time the Internet access connection should be
disconnected (Force Down).
Office
Hour:
(Force On)
Mon - Sun
1. Make sure the PPPoE connection and Time Setup is working properly.
2. Configure the PPPoE always on from 9:00 to 18:00 for whole week.
3. Configure the Force Down from 18:00 to next day 9:00 for whole week.
4. Assign these two profiles to the PPPoE Internet access profile. Now, the PPPoE Internet
connection will follow the schedule order to perform Force On or Force Down action
according to the time plan that has been pre-defined in the schedule profiles.
I I - 5 - 5 R A
I I - 5 - 5 R A
Remote Authentication Dial-In User Service (RADIUS) is a security authentication
client/server protocol that supports authentication, authorization and accounting, which is
widely used by Internet service providers. It is the most common method of authenticating
and authorizing dial-up and tunneled network users.
I I I I - - 5 5 - - 5 5 - - 1 1 E E
The built-in RADIUS client feature enables the router to assist the remote dial-in user or a
wireless station and the RADIUS server in performing mutual authentication. It enables
centralized remote access authentication for network management.
Vigor router can be operated as a RADIUS client. Therefore, this page is used to configure
settings for external RADIUS server. Then LAN user of Vigor router will be authenticated by
such server for network application.
Vigor2926 Series User's Guide
Specify which action should be applied during the period of
the schedule.
Force On -Force the connection to be always on.
Force Down -Force the connection to be always down.
Specify how often the schedule will be applied.


Specify the days to reset the traffic record. For example, 7
means the whole cycle is 7 days; 20 means the whole cycle is
20 days. When the time is up, the router will reset the traffic
record automatically.
9:00 am
D I U S / T A C A C S +
D I U S / T A C A C S +
x x t t e e r r n n a a l l R R A A D D I I U U S S
Once -The schedule will be applied just once
Weekdays -Specify which days in one week should
perform the schedule.
to 6:00 pm
