MAC Address Filter
Client's MAC Address
Apply SSID
Attribute
Add
Delete
Edit
Cancel
OK
Clear All
After finishing all the settings here, please click OK to save the configuration.
I I I - 1 - 5 W
I I I - 1 - 5 W
WPS (Wi-Fi Protected Setup) provides easy procedure to make network connection between
wireless station and wireless access point (vigor router) with the encryption of WPA and
WPA2.
Info
It is the simplest way to build connection between wireless network clients and vigor router.
Users do not need to select any encryption mode and type any long encryption passphrase to
setup a wireless client every time. He/she only needs to press a button on wireless client, and
WPS will connect for client and router automatically.
There are two methods to do network connection through WPS between AP and Stations:
pressing the Start PBC button or using PIN Code.
Vigor2926 Series User's Guide
Display all MAC addresses that are edited before.
Manually enter the MAC address of wireless client.
After entering the client's MAC address, check the box of the
SSIDs desired to insert this MAC address into their access
control list.
s: Isolate the station from LAN - select to isolate the
wireless connection of the wireless client of the MAC address
from LAN.
Add a new MAC address into the list.
Delete the selected MAC address in the list.
Edit the selected MAC address in the list.
Give up the access control set up.
Click it to save the access control list.
Clean all entries in the MAC address list.
P S
P S
WPS is available for the wireless station with WPS supported.
