Draytek Vigor2926L User Manual page 53

P P T P / L 2
P P T P / L 2
1. Choose WAN1/WAN2 as the WAN Interface and click the Next button. The following
page will be open for you to specify Internet Access Type.
2. Click PPTP/L2TP as the Internet Access Type. Then click Next to continue.
Available settings are explained as follows:
Item
Username
Password
Confirm Password
WAN IP Configuration
Vigor2926 Series User's Guide
T P
T P
Description
Assign a specific valid user name provided by the ISP.
Note: The maximum length of the user name you can set is
63 characters.
Assign a valid password provided by the ISP.
Note: The maximum length of the password you can set is 62
characters.
Retype the password.
Obtain an IP address automatically – the router will get an
IP address automatically from DHCP server.
37
