An easy and quick method is offered to configure VPN settings for building VPN connection
automatically between Vigor2926 series (treated as VPN server) and other Vigor router
(treated as CPE device, i.e., VPN client).
Available parameters are listed as follows:
Item
CPE VPN Connection List
VPN
Type
Remote IP
Virtual Network
Tx Pkts
Tx Rate(Bps)
Rx Pkts
Rx Rate(Bps)
Up Time
Once the device is managed (controlled) by Vigor2926 series, it will be displayed on such
screen automatically. If not, refer to sections "How to manage the CPE (router) through
Vigor2926?" for more detailed information.
542
P N M a n a g e m e n t
P N M a n a g e m e n
Description
Display the name of the LAN-to-LAN profile.
It is generated automatically when you click the
PPTP/IPsec/Advanced button to build the VPN connection
between Vigor2926 and remote CPE.
Display the dial-in type and the authentication method.
Display the IP address of the remote CPE and the interface.
Display the IP address and subnet mask of Vigor2926 series.
Display the number of the transmitted packets.
Display the number of the transmitted rate.
Display the number of the received packets.
Display the number of the received rate.
Display the connection time of such VPN.
