Draytek Vigor2926L User Manual page 144

Strict Bind
ARP Table
Select All
Sort
Refresh
Add or Update
IP Bind List
Add
Update
Delete
Backup
Restore
Info
When you finish the configuration, click OK to save the settings.
128
Check it to block the connection of the IP/MAC which is not
listed in IP Bind List.
Apply Strict Bind to Subnet – Click Edit to shoose the
subnet(s) for applying the rules of Bind IP to MAC.
This table is the LAN ARP table of this router. The
information for IP and MAC will be displayed in this field.
Each pair of IP and MAC address listed in ARP table can be
selected and added to IP Bind List by clicking Add below.
Click this link to select all the items in the ARP table.
Reorder the table based on the IP address.
Refresh the ARP table listed below to obtain the newest ARP
table information.
IP Address – Type the IP address that will be used for the
specified MAC address.
Mac Address – Type the MAC address that is used to bind
with the assigned IP address.
Comment – Type a brief description for the entry.
Show Comment – Check this box to display the comment on
IP Bind List box.
It displays a list for the IP bind to MAC information.
It allows you to add the one you choose from the ARP table or
the IP/MAC address typed in Add and Edit to the table of IP
Bind List.
It allows you to edit and modify the selected IP address and
MAC address that you create before.
You can remove any item listed in IP Bind List. Simply click
and select the one, and click Delete. The selected item will
be removed from the IP Bind List.
Store the configuration for Bind IP to MAC as a file.
Restore the previously stored configuration file and apply to
such page.
Before you select Strict Bind, you have to bind one set of IP/MAC address for
one PC. If not, no one of the PCs can access into Internet. And the web user
interface of the router might not be accessed.
