T e l n e t C o m m
T e l n e t C o m m
This command allows users to configure settings for BGP.
S S y y n n t t a a x x
ip bgp mode [0/1]
ip bgp as [value]
ip bgp hold [value]
ip bgp retry [value]
ip bgp id [value]
ip bgp show
ip bgp neighbor [idx] mode [0/1]
ip bgp neighbor [idx] name [max len: 20]
ip bgp neighbor [idx] ip [x.x.x.x]
ip bgp neighbor [idx] as [1~4294967295]
ip bgp neighbor [idx] show
ip bgp neighbor show all
ip bgp static [sidx][ip][<netmask]
ip bgp static [sidx] delete
ip bgp static show
S y n t a x
S y n t a x
Parameter
mode <0/1>
as <value>
hold <value>
retry <value>
id <value>
show
neighbor <idx> mode <0/1>
neighbor <idx> name <max
len: 20>
Vigor2926 Series User's Guide
a n d : i p b g p
a n d : i p b g p
D e s c r i p t i o n
D e s c r i p t i o n
Description
It means to enable / disable BGP mode.
0: disable
1: enable
It means to set the AS number for local router.
<value>: Available number is between 0 and 4294967295.
It means to set the time interval to determine the peer is dead
when the router is unable to receive any keepalive message from
the peer within the time.
<value>: Available number is between 10 and 65535 (unit: second).
The default is 180 (seconds).
It means to set a period of time to reconnect if the router fails to
connect to the neighboring router.
<value>: Available number is between 3 and 255 (unit: second). The
default is 120 (seconds).
It means to specify the LAN subnet <1~16> as router ID.
<value>: Available number is between 1 and 16.
It means to display information related to BGP settings.
It means to enable / disable the basic BGP function for neighboring
router.
<idx>: Available profile number is between 1 and 8.
<0/1>: 0- disable; 1- enable
It means to define a profile name for neighboring router.
<idx>: Available profile number is between 1 and 8.
<max len>: The maximum name length shall not be over 20
