SMS service status : Ready
Number of SMS sent : 0
T e l n e t C o m m
T e l n e t C o m m
This command allows you to configure WAN connection detection. When Ping Detection is
enabled (for Static IP or DHCP or PPPoE mode), Router pings specified IP addresses to detect
the WAN connection.
S S y y n n t t a a x x
wan detect [wan1/wan2][on/off/always_on]
wan detect [wan1/wan2] target [ip addr]
wan detect [wan1/wan2] target2[ip addr]
wan detect [wan1/wan2] target_gw [1/0]
wan detect [wan1/wan2] ttl [value]
wan detect [wan1/wan2] interval [interval]
wan detect [wan1/wan2] retry [retry]
wan detect status
S y n t a x
S y n t a x
Parameter
on
off
always_on
target
Target2
Target_gw
ip addr
ttl
interval [interval]
retry [retry]
status
E E x x a a m m p p l
> wan detect status
WAN1: always on
WAN2: off
WAN3: off
Vigor2926 Series User's Guide
a n d : w a n d e t e c t
a n d : w a n d e t e c t
D e s c r i p t i o n
D e s c r i p t i o n
Description
Enable ping detection. The IP address of the target shall be set.
Enable ARP detection (default).
Disable link detect, always connected(only support static IP)
Set the ping target.
Set the secondary ping target.
Set whether to use gateway as ping target. (1: yes 0: no)
Note that USB WAN (PPP mode) cannot support PING gateway
It means the IP address used for detection. Type an IP address in this
field.
It means to set the ping TTL value (work as trace route)
If you do not set any value for ttl here or just type 0 here, the
system will use default setting (255) as the ttl value.
Set the interval between each ping operation. Available setting is
between 1 and 3600. The unit is second.
[interval]: Type a value.
Set how many ping operations are retried before the Router judges
that the WAN connection is disconnected. Available setting is
between 1 and 255. The unit is times.
[retry] : Type a number.
It means to show the current status.
l e e
885
