Specifications - Icom ID-31E PLUS Basic Manual

D Transmitter
• Modulation system:
FM/FM-N
DV
• Output power:
• Maximum frequency deviation:
FM
FM-N
• Spurious emissions:
• Microphone impedance:
Variable reactance frequency
modulation
GMSK reactance frequency
modulation
High: 5.0 W, Mid: 2.5 W,
Low 2: 1.0 W, Low 1: 0.5 W,
S-Low: 0.1 W
±5.0 kHz
±2.5 kHz
Less than –60 dBc at High/Mid
Less than –13 dBm at Low 2/
Low 1/S-Low
2.2 k˘
D Receiver
• Receive system:
• Intermediate frequencies:
• Sensitivity:
FM
DV
• Audio output power:
Internal speaker
External speaker
• Selectivity:
FM
FM-N
DV
• Spurious and image rejection ratio:
• Squelch Sensitivity (threshold):

specifications

Double Conversion
Superheterodyne
1st IF 46.35 MHz, 2nd IF 450 kHz
Less than 0.18 μV
(at 12 dB SINAD)
Less than 0.28 μV
(1% BER)
More than 0.4 W at 10% distortion
into a 16 Ω load
More than 0.2 W at 10% distortion
into an 8 Ω load
More than 55 dB
More than 50 dB
More than 50 dB
More than 60 dB
Less than 0.18 μV
Basic ManUaL
