8
MDC 1200 SYSTEM OPERATION
Transmitting a call

D Transmitting an MDC Radio Check call

An MDC Radio Check call enables the user to
determine whether the targeted station is turned ON,
within the communication range and on the channel,
without requiring any action from the targeted station
user�
(Menu > Signaling/Call > Call Menu)
1� Push [Menu] to display the Menu screen�
2� Push [P2 (Up)] or [P1 (Down)] to select "Signaling/
Call," then push [OK]�
Menu
Channel/Scan
Signaling/Call
3� Push [P2 (Up)] or [P1 (Down)] to select "Call
Menu," then push [OK]�
Signaling/Call
Call List Select
Call Menu
4� Push [P2 (Up)] or [P1 (Down)] to select a station
ID, then push [OK]�
Call Menu
✔ ID 1
ID A01
✔
5� Push [P2 (Up)] or [P1 (Down)] to select "Radio
Check," then push [PTT] to transmit an MDC
Radio Check call�
Station 1
Radio Check
✔
Stun
✔
• "Success" is displayed when an acknowledgment is
received from the targeted station�
• "Failed" is displayed if an acknowledgment is not
received from the targeted station�
TIP: Push [Call Menu] to directly display the "Call
Menu" screen in step 4 above�
►
►
►
►
►
►

D Transmitting an MDC Stun call

An MDC Stun call remotely disables the transceiver�
(Menu > Signaling/Call > Call Menu)
1� Push [Menu] to display the Menu screen�
2� Push [P2 (Up)] or [P1 (Down)] to select "Signaling/
Call," then push [OK]�
Menu
Channel/Scan
Signaling/Call
3� Push [P2 (Up)] or [P1 (Down)] to select "Call
Menu," then push [OK]�
Signaling/Call
Call List Select
Call Menu
4� Push [P2 (Up)] or [P1 (Down)] to select a station
ID, then push [OK]�
Call Menu
✔ ID 1
ID A01
✔
5� Push [P2 (Up)] or [P1 (Down)] to select "Stun,"
then push [PTT] to transmit an MDC Stun call�
Station 1
Stun
✔
Revive
✔
• "Success" is displayed when an acknowledgment is
received from the targeted station�
• "Failed" is displayed if an acknowledgment is not
received from the targeted station�
TIP: Push [Call Menu] to directly display the "Call
Menu" screen in step 4 above�
8-5
►
►
►
►
►
►
