2
PANEL DESCRIPTION
Assignable Software key functions (Continued)
Category: Channel/Scan (Voting) (Continued)
Scan Add/Del (Tag)
z Push to add a channel to, or delete it from the
current Scan list�
• When a channel is added to the current Scan list, the
current Scan list text and "ON" are briefly displayed.
• When a channel is deleted from the current Scan
list, the current Scan list text and "OFF" are briefly
displayed�
z You can add a channel to, or delete it from a
selected Scan list�
1� Hold down for 1 second to display the "Scan Tag"
screen�
2� Push [Up] or [Down] to select a list�
3� Push [OK] to add a channel to, or delete it from
the selected list�
• When a channel is added to the selected Scan
list, the current Scan list text and "ON" are briefly
displayed�
• When a channel is deleted from the selected Scan
list, the current Scan list text and "OFF" are briefly
displayed�
4� Push [Back] to exit the "Scan Tag" screen�
z While a Scan is paused by detecting a signal on a
channel (except for primary or secondary channel),
push this key to remove the channel from the Scan
list�
TIP: When the Nuisance Delete function is ON,
the removed channel is automatically added to the
Scan list again, after the Scan is canceled�
High/Low
Push to select the transmit output power level
temporarily or permanently, depending on the
presetting�
C.Tone CH Select
In the Analog mode
Push to display the "C�Tone CH Select" screen� Then
push [Up] or [Down] to select a tone frequency or
code� After selecting, push [OK] to save�
Tone/RAN CH Select
In the Analog mode
Push to display the "C�Tone CH Select" screen� Then
push [Up] or [Down] to select a tone frequency or
code� After selecting, push [OK] to save�
In the Digital mode
Push to display the "RAN CH Select" screen� Then
push [Up] or [Down] to select a RAN code� After
selecting, push [OK] to save�
Monitor
z Push to turn the CTCSS (DTCS), 2-Tone, or 5-Tone
squelch mute ON or OFF�
L Only during 2-Tone mode operation, push to open any
squelch, or deactivate any mute functions�
L Only during 5-Tone mode operation, push to activate
one or two of the following functions on each channel
(Depending on the presetting):
- Hold down to unmute the channel (Audible mode)�
- Push to mute the channel (Inaudible mode)�
NOTE: The audible (unmute) mode may
automatically return to the Inaudible (mute) mode,
after the preset time period�
z Depending on the presetting, holding down this key
for 1 second may cancel the Scan�
Talk Around
Push to turn the Talk Around function ON or OFF�
L The Talk Around function equalizes the transmit
frequency to the receive frequency, for direct (Simplex)
communication�
Bandwidth
In the Analog mode
Push to temporarily set the channel width to Wide* or
Narrow�
L The wide passband width can be preset to either 25�0
kHz (Wide) or 20�0 kHz (Mid)�
Depending on the presetting, Mid channel width may be
selectable�
* The Wide channel width cannot be used in the USA
version transceivers�
Scrambler/Encryption
In the Analog mode
Push to turn the Voice Scrambler function ON or OFF�
L The Voice Scrambler function provides private
communication between stations by using a scrambled
code�
In the Digital mode
Push to turn the Encryption function ON or OFF�
L The Voice or Data Encryption function provides private
communication between stations by using an Encryption
Key and Key ID�
Compander
In the Analog mode
Push to turn the Compander function ON or OFF�
L The Compander function reduces noise components on
the transmit audio to provide clear communication�
2-10
