OPERATING GUIDE
OPERATING GUIDE FOR
IC-F3210D/F4210D/F3230D/
F4230D/F5220D/F6220D SERIES
IDAS™ NXDN™ OPERATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC-F3210D and is the answer not in the manual?

Questions and answers

Related Manuals for Icom IC-F3210D

Summary of Contents for Icom IC-F3210D

  • Page 1 OPERATING GUIDE OPERATING GUIDE FOR IC-F3210D/F4210D/F3230D/ F4230D/F5220D/F6220D SERIES IDAS™ NXDN™ OPERATION...

  • Page 2: Table Of Contents

    ID and message cannot be input with this microphone. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incor- porated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries.

  • Page 3: Preparation

    IC-F3210D/F4210D series transceivers: [Upper] and [Lower] IC-F3230D/F4230D series transceivers: [P0], [P1], [P2], [P3], [Side1], [Side2], [Side3] and [Emer] IC-F5220D/F6220D series transceivers: [UP], [DOWN], [P0], [P1], [P2] and [P3] Consult your Icom dealer or system operator for details con- cerning your transceiver’s programming.
  • Page 4 PREPARATION Programmable key functions (Continued) ■ Programmable key functions availability Analog Digital Programmable key Reference IC-F3210D/ IC-F3230D/ IC-F5220D/ IC-F3210D/ IC-F3230D/ IC-F5220D/ functions F4210D series F4230D series F6220D series F4210D series F4230D series F6220D series CH Up/Down ✔ ✔ ✔ ✔...
  • Page 5 PREPARATION Analog Digital Programmable key Reference IC-F3210D/ IC-F3230D/ IC-F5220D/ IC-F3210D/ IC-F3230D/ IC-F5220D/ functions F4210D series F4230D series F6220D series F4210D series F4230D series F6220D series Encryption p. 4 ✔ ✔ ✔ Hook Scan ✔ ✔ User Set Mode ✔ ✔...
  • Page 6 While in the analog mode, after the Start or Repeat timer period ends, the microphone audio may be automatically <For the IC-F3210D/F4210D series transceivers> transmitted, depending on the presetting. Hold down for 1 second to turn ON the Lone Worker func- ➥...
  • Page 7 PREPARATION DIGITAL BUTTON STATUS UP, STATUS DOWN <For the IC-F3210D/F4210D series transceivers> <For the IC-F3210D/F4210D series transceivers> <For the IC-F3230D/F4230D/F5220D/F6220D series transceivers> <For the IC-F3230D/F4230D/F5220D/F6220D series transceivers> Push to enter the application selection mode*. When a received SDM (Short Data Message) is displayed, ➥...
  • Page 8 Programmable key functions ■ Programmable key functions (Continued) INDIVIDUAL RESET <For the IC-F3210D/F4210D series transceivers> Push to reset the destination unit ID and call type to the ➥ default, if they have been changed by the manual opera- tion. <For the IC-F3230D/F4230D/F5220D/F6220D series transceivers>...
  • Page 9 PREPARATION SITE SELECT STATUS <For the IC-F3210D/F4210D series transceivers> <For the IC-F3210D/F4210D series transceivers> Hold down for 1 second to transmit the currently selected sta- tus message to the specified station/Talkgroup. <For the IC-F3230D/F4230D/F5220D/F6220D series transceivers> (This key is used for only Multi-site Trunk operation.) <For the IC-F3230D/F4230D/F5220D/F6220D series transceivers>...

  • Page 10: Idas Operation

    IDAS OPERATION IDAS operation ■ Single-site Trunking operation The transceiver provides Icom Digital Advanced System (IDAS) that meets the 6.25 kHz emission mask requirements The Single-site Trunking system enables further effective for narrow banding, and increases efficiency of channel al-...

  • Page 11: Receiving A Call

    For the IC-F5220D/F6220D series transceivers For the IC-F5220D/F6220D series transceivers Hold down [PTT], then speak into the microphone. Release [PTT] to receive a response. Except for the IC-F3210D/IC-F4210D series transceivers. Only for the IC-F3210D/IC-F4210D series transceivers. Continued on the next page ☞...
  • Page 12 • The LED may blink orange once or twice, depending on the pre- setting.* For the IC-F3230D/F4230D series transceivers For the IC-F5220D/F6220D series transceivers Push [PTT], change the channel, turn power OFF, and so Except for the IC-F3210D/IC-F4210D series transceivers. Only for the IC-F3210D/IC-F4210D series transceivers. on to stop the display indication.

  • Page 13: Receiving A Message

    Example: A message “RETURN TO OFFICE” from a station 1 is displayed on the IC-F3230D/F4230D series transceiver. For the IC-F5220D/F6220D series transceivers Push [PTT], change the channel, turn power OFF, and so Except for the IC-F3210D/IC-F4210D series transceivers. on to stop the display indication. Only for the IC-F3210D/IC-F4210D series transceivers.
  • Page 14 RAN code matching may not be necessary, Except for the IC-F3210D/IC-F4210D series transceivers. depending on the presetting. Depending on the received Stun command setting. When a Remote monitor command is received: ➥...
  • Page 15 ON for the preprogrammed time period. (Auto Backlight Timer)* Turn power OFF or change the channel to stop the beep * Except for the IC-F3210D/IC-F4210D series transceivers. and display indication. For the IC-F3230D/F4230D series transceivers For the IC-F5220D/F6220D series transceivers...
  • Page 16 IDAS OPERATION Receiving a call (Continued) ■ Displaying the received call log The transceiver stores a log of all calls in memory, if acti- Push [Digital Button] again to display the call log informa- vated. tion. Up to 10 call logs can be stored, and the oldest call record When a log information is displayed is erased when an 11th call is received.
  • Page 17 IDAS OPERATION When no log information is available For the IC-F3230D/F4230D series transceivers For the IC-F5220D/F6220D series transceivers Push [CH Up] or [CH Down] to select the desired log. Hold down [PTT] to send the voice call. • A voice call can be made with the logged station.

  • Page 18: Transmitting A Call

    IDAS OPERATION Transmitting a call ■ IDAS operation allows you to make a call to a specific station For the IC-F3230D/F4230D series transceivers (Individual call) or to a particular group (Talkgroup call). Other digital mode transceivers on the channel will not receive a call that does not match their individual or talkgroup ID and/or RAN (Radio Access Number) code.
  • Page 19 IDAS OPERATION Push [Digital Button] again to enter the destination ID se- Hold down [PTT], then speak into the microphone to send lection mode. a voice message to the selected station or talkgroup. • The preprogrammed ID name is displayed. Release [PTT] to receive.
  • Page 20 Push [Digital Button] to enter the application selection mode. < For the IC-F3210D/IC-F4210D series transceivers> • “VOICE” appears. [CallAlert] to transmit the Call Alert to the Hold down • To change the call type, hold down [Digital Button] for 1 second specified station or Talkgroup.
  • Page 21 (or ID code). tus message. There are 100 status messages that can be sent. For the IC-F3230D/F4230D series transceivers < For the IC-F3210D/IC-F4210D series transceivers> Hold down [Status] to transmit the status message to the specified station or talkgroup. • The LED indicator blinks orange while accessing a channel to make a call.
  • Page 22 IDAS OPERATION Transmitting a call ■ Transmitting a Status Message (Continued) < For the IC-F3230D/IC-F4230D series and Push [CH Up] or [CH Down] to select the desired mes- IC-F5220D/IC-F6220D series transceivers> sage. Push [Digital Button] to enter the application selection For the IC-F3230D/F4230D series transceivers mode.
  • Page 23 IDAS OPERATION Push [PTT] to transmit the status message to the selected Push [Digital Button] again to enter the destination ID se- station or talkgroup. lection mode. • “STAT TX” is displayed. • The preprogrammed ID name is displayed. Release [PTT]. •...

  • Page 24: Transmitting A Message

    IDAS OPERATION Transmitting a call (Continued) ■ Transmitting a Message < For only the IC-F3230D/IC-F4230D series and Push [CH Up] or [CH Down] to select the desired mes- IC-F5220D/IC-F6220D series transceivers> sage. The transceiver has the ability to send a preprogrammed •...
  • Page 25 IDAS OPERATION Push [PTT] to transmit the message to the selected station Push [Digital Button] again to enter the destination ID se- or talkgroup. lection mode. • “MSG TX” is displayed. • The preprogrammed ID name is displayed. Release [PTT]. •...
  • Page 26 IDAS OPERATION Transmitting a call (Continued) ■ Direct message input (10-key version only) • Available characters Push [Digital Button] to enter the application selection mode. Characters • “VOICE” appears. 0 | ! ? ’ ” , ; : _ ( ) < > [ ] •...
  • Page 27 IDAS OPERATION Transmitting an Emergency Call When [Emergency] is held down for a specified time period, IMPORTANT: It is recommended an emergency channel be a digital command emergency signal is transmitted once or separately set to provide reliable emergency call operation. repeatedly* on the emergency channel.
  • Page 28 IDAS OPERATION Transmitting a call (Continued) ■ Direct ID input Direct ID list number input (10-key version only) (10-key version only) Depending on the presetting, you can directly input the de- Depending on the presetting, you may select the Individual or sired Individual or Talkgroup ID.

  • Page 29: Position Data Transmission

    IDAS OPERATION Position data transmission Status message transmission ■ ■ When a GPS receiver is connected to the transceiver, the lon- The status message can be automatically transmitted. gitude and latitude position data can be automatically trans- The status message is transmitted when: mitted when: •...

  • Page 30: Auto Ch Reserve Function

    IDAS OPERATION Auto CH Reserve function Talk Back function ■ ■ If enabled, this feature is effective when a subscriber attempts The Talk Back function allows you to select the same call type to push [PTT] while the site is in an “All Trunks Busy” status, (Individual or Talkgroup) for the received call.

  • Page 31: Roaming Function (Multi-Site Trunking Mode Only)

    IDAS OPERATION Roaming function Site Lock function ■ ■ (Multi-site Trunking mode only) (Multi-site Trunking mode only) The Multi-site Trunking mode allows the transceiver to move The [Site Lock] key allows you to lock the transceiver to the to another site, according to the preprogrammed roaming currently registered site, and the roaming and the background list*, in order to find a site that has a higher quality signal, or scans are inhibited.
  • Page 32 A-7084-1EX-w 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan © 2013 Icom Inc.
