3

Getting Started

This chapter provides information on how to install the necessary
components on the cPCI-6810/6820 and cPCI-R6820 RTM. The
topics covered are:
CPU and heat sink

Memory module installation

HDD installation on main board
HDD installation on RTM
CF installation on RTM
PMC installation
RTM installation
Main board installation

3.1 CPU and Heatsink

The cPCI-6810/6820 SBC supports the Intel® Pentium® III
Processor - Low Power up to 1033MHz, which is pre-mounted to
the PCB (printed circuit board). The heatsink has also been pre-
mounted in the factory. There is no jumper setting necessary to
set the CPU operating frequency or CPU type.
WARNING: DO NOT try to replace the CPU in the field or remove
the heatsink. It will cause board defects and void all
warranty for the board.
3.2 Memory Module Installation
The cPCI-6810/6820 SBC supports up to four sockets of 144-pin
PC-133 registered ECC SO-DIMMs. The maximum memory
capacity is therefore 2GB. If memory modules are pre-installed
when the package is received, this section can be skipped.
Getting Started
51
