cPCI-R6820 Features
PICMG 2.0 CompactPCI Specification R3.0 Compliant
6U form factor, 1-slot (4TE/HP) in width, 80mm in board
depth
Designed for cPCI-6810 and 6820 series front board
Supports dual RJ-45 GbE connectors, onboard dual EIDE
interfaces with CF socket and housing for onboard 2.5" ATA
HDD
Supports two USB ports (type A connector), COM port over
RJ-45 connector, one VGA port, keyboard and mouse
combo connector, and an optional COM2 connector.
4
Introduction
