Page 1: Reference Manual
CoreModule 740 Single Board Computer Reference Manual P/N 50-1Z046-1000... - Page 2 Notice Page DISCLAIMER ADLINK Technology, Incorporated makes no representations or warranties with respect to the contents of this manual or of the associated ADLINK products, and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose. ADLINK shall under no circumstances be liable for incidental or consequential damages or related expenses resulting from the use of this product, even if it has been notified of the possibility of such damages.
-
Page 3: Table Of Contents
Utility 2 Pin Signals ........................23 Video (VGA/LVDS) Interface ......................26 System Fan............................27 Power Interface ..........................27 Miscellaneous ..........................28 Real Time Clock (RTC) ......................28 Oops! Jumper (BIOS Recovery) ....................28 Serial Console ..........................28 Serial Console Setup......................28 Hot (Serial) Cable .......................28 Watchdog Timer ........................29 CoreModule 740 Reference Manual... - Page 4 I/O Interface Board Layout ....................... 35 I/O Interface Board Connectors and Headers ................36 Index ..............................41 List of Figures Figure 2-1. Stacking PC/104-Plus Modules with the CoreModule 740 ........4 Figure 2-2. Functional Block Diagram ..................6 Figure 2-3. Component Locations (Top-Side View)..............8 Figure 2-4.
-
Page 5: Chapter 1 About This Manual
For latest revision of the PCI specifications, contact the PCI Special Interest Group at: Web site: http://www.pcisig.com Chip Specifications The following integrated circuits (ICs) are used in the CoreModule 740 single board computer: • Intel® Corporation and the N450 processor Web site: http://www.intel.com/products/processor/atom/techdocs.htm... - Page 6 If you are unable to locate the datasheets using the links provided, go to the manufacturer’s web site where you can perform a search using the chip datasheet number or name listed, including the extension (htm for web page, pdf for files name, etc.) Reference Manual CoreModule 740...
-
Page 7: Chapter 2 Product Overview
The PC/104 architecture affords a great deal of flexibility in system design. You can build a simple system using only a CoreModule 740, an input/output device connected to the serial or parallel ports, and an IDE storage device connected to the IDE port. To expand a simple CoreModule system, simply add self-stacking PC/104 and PC/104-Plus expansion boards to provide additional capabilities, such as: •... -
Page 8: Product Description
It can be stacked with ADLINK MiniModules™ or other PC/104-compliant expansion modules, or it can be used as a powerful computing engine. The CoreModule 740 requires a single +5V AT power source. -
Page 9: Module Features
• Provides two USB ports • Supports USB V2.0 Support external reset switch ♦ Support standard external 8 speaker interface ♦ Ω Support HDD Activity LED ♦ Support external battery for Real Time Clock operation ♦ CoreModule 740 Reference Manual... -
Page 10: Block Diagram
RS-232 SCH3112I-NU (COM1) Transceiver PS/2 (COM2) Floppy 80-pin Utility Connector 1 80-pin Utility Connector 2 2 Serial 2 USB Keyboard/ Ports Ports Mouse Speaker Parallel Floppy Reset HDD LED Battery Switch Figure 2-2. Functional Block Diagram Reference Manual CoreModule 740... -
Page 11: Major Components (Ics)
Chapter 2 Product Overview Major Components (ICs) Table 2-1 lists the major ICs, including a brief description of each, on the CoreModule 740. Figures 2-3 show the locations of the major ICs. Table 2-1. Major Component Descriptions and Functions Chip Type Mfg. -
Page 12: Figure 2-3. Component Locations (Top-Side View)
Figure 2-3. Component Locations (Top-Side View) Key: U8 - ISA Bridge U9 - SIO U11 - RS-232 Transceiver1 U12 - RS-232 Transceiver2 U13 - CPU Thermometer U28 - SDRAM 2 U30 - SDRAM 4 Figure 2-4. Component Locations (Bottom-Side View) Reference Manual CoreModule 740... -
Page 13: Header And Connector Definitions
Chapter 2 Product Overview Header and Connector Definitions Table 2-2 describes the headers and connectors of the CoreModule 740 shown in Figures 2-6 and 2-7. Table 2-2. Module Header and Connector Descriptions Header # Board Description Access J1 A, B, C, D –... -
Page 14: Figure 2-6. Header And Connector Locations (Top-Side View)
Figure 2-6. Header and Connector Locations (Top-Side View) Key: J8 - Not Populated J9 - Not Populated J10 - Video J11 - Not Populated J12 - Not Supported Figure 2-7. Header and Connector Locations (Bottom-Side View) Reference Manual CoreModule 740... -
Page 15: Jumper Header Definitions
This measurement does not include the Board thickness 2.362 mm (0.093 inches) heatsink, which can vary. The heatsink Width 90.169 mm (3.55 inches) could increase this dimension. Length 95.884 mm (3.775 inches) CoreModule 740 Reference Manual... -
Page 16: Mechanical Specifications
NOTE All dimensions are given in inches. Pin 1 is shown as a black square on headers and connectors. Black squares on right-angle headers indicate pin 2 in top-side views and pin 1 in bottom-side views. Reference Manual CoreModule 740... -
Page 17: Power Specifications
5% to 95% relative humidity, non-condensing Thermal/Cooling Requirements The CPU is the primary source of heat on the board. The CoreModule 740 is designed to operate at the maximum speed of the CPU and requires a heatsink (provided). CoreModule 740... - Page 18 Chapter 2 Product Overview Reference Manual CoreModule 740...
-
Page 19: Chapter 3 Hardware
ADLINK Technology, Inc. only supports the features/options tested and listed in this manual. The main chips used in the CoreModule 740 may provide more features or options than are listed for the CoreModule 740, but some of these features/options are not supported on the module and will not function as specified in the chip documentation. -
Page 20: Interrupt Channel Assignments
Legend: D = Default, O = Optional, X = Fixed NOTE The IRQs for USB and Video are automatically assigned by the BIOS Plug and Play logic. Local IRQs assigned during initialization can not be used by external devices. Reference Manual CoreModule 740... -
Page 21: Memory Map
0070-007F CMOS RAM, NMI Mask Reg, RT Clock 0080 System reserved 0081-0083 DMA Page Registers 0084-0086 System reserved 0087 DMA Page Register 0088 System reserved 0089-008B DMA Page Registers 008C-008E System reserved 008F DMA Page Register CoreModule 740 Reference Manual... - Page 22 0279h and 0A79h are the ISA PnP ports used by the BIOS and an OS that supports this feature to recognize ISA PnP (Plug and Play) cards. The Intel I/O hub ICH-8 (ICH-6 or later) does not support ISA DMA. Reference Manual CoreModule 740...
-
Page 23: Utility 1 Interface
Hardware Utility 1 Interface The CoreModule 740 provides two utility interface connectors. Both interfaces, Utility 1 (J5) and Utility 2 (J4), use identical 80-pin connectors. This section describes the Utility 1, J5 interface, which supports the features listed in the following bullets. -
Page 24: Speaker
Serial Data Terminal Ready 1 – Indicates port is powered, initialized, and ready. Used as hardware handshake with DSR1 for overall readiness to communicate. Parallel Port Data 2 – This signal provides parallel data to the printer. Reference Manual CoreModule 740... -
Page 25: Table 3-4. Utility 1 Interface Pin Signals (J5)
PP_BUSY Parallel Printer Busy – This is a status output signal from the printer. A high state indicates the printer is not ready to accept data. USBPwr1 +5 volts +/-5% (USB1 Power) GND9 Ground 9 (Serial) CoreModule 740 Reference Manual... - Page 26 External Backup Battery Positive – External positive battery terminal. Not Connected BATV- External Backup Battery Negative – External battery ground. Note: The shaded areas denote power or ground. The signals marked with * indicate active low. Reference Manual CoreModule 740...
-
Page 27: Utility 2 Interface
Primary Disk Data 4 FDD_MTR0 Floppy Motor Control 0 – Selects drive motor 0 IDE_PDD11 Primary Disk Data 11 GND13 Floppy Ground IDE_PDD3 Primary Disk Data 3 Not Connected IDE_PDD12 Primary Disk Data 12 GND14 Floppy Ground CoreModule 740 Reference Manual... - Page 28 Primary I/O DMA Channel Ready – When negated extends the host transfer cycle of any host register access when the drive is not ready to respond to a data transfer request. High impedance if asserted. FDD_WPRT* Floppy Write Protect – Senses the diskette is write protected Reference Manual CoreModule 740...
- Page 29 Primary IDE Drive Activity LED – Used to drive an external IDE activity LED, indicating drive activity Not Connected GND5 IDE Ground Note: The shaded areas denote power or ground. The signals marked with * indicate active low. CoreModule 740 Reference Manual...
-
Page 30: Video (Vga/Lvds) Interface
Digital to Analog Converter – Green Output to the CRT GREEN_RETURN VGA Ground for Green Output CON_DAC_BLUE Digital to Analog Converter – Blue Output to the CRT BLUE_RETURN VGA Ground for Blue Output CRT_HSYNC Horizontal Sync – Digital Horizontal Sync Output to the CRT Reference Manual CoreModule 740... -
Page 31: System Fan
Note: The shaded areas denote power or ground. Power Interface The CoreModule 740 requires one +5 volt DC power source and provides a 10-pin, shrouded header with 2 rows, odd/even pin sequence (1, 2), and 0.100" (2.54mm) pitch. If the +5VDC power drops below ~4.65V, a low voltage reset is triggered, resetting the system. -
Page 32: Miscellaneous
Real Time Clock (RTC) The CoreModule 740 contains a Real Time Clock (RTC). The RTC can be backed up with a battery. If the battery is not present, the board BIOS has a battery-less boot option to complete the boot process. -
Page 33: Watchdog Timer
Support Software QuickDrive illustrating how to control the WDT. The code examples can be easily copied to your development environment to compile and test the examples, or make any desired changes before compiling. Refer to the WDT Readme file on the CoreModule 740 Support Software QuickDrive. - Page 34 Chapter 3 Hardware Reference Manual CoreModule 740...
-
Page 35: Chapter 4 Bios Setup
This section describes how to enable the Remote Access in VGA mode and enter the BIOS setup through a serial terminal or PC. Turn on the power supply to the CoreModule 740 and enter the BIOS Setup Utility in VGA mode. Set the BIOS feature Remote Access Configuration to [Enable] under the Advanced menu. -
Page 36: Pci-Isa Bridge Mapping
IRQs from “Available” to “Reserved”. OEM Logo Utility The CoreModule 740 BIOS supports a graphical logo utility, which can be customized by the user and displayed when enabled through the BIOS Setup Utility. The graphical image can be a company logo or any custom image the user wants to display during the boot process. -
Page 37: Appendix A Technical Support
Appendix A Technical Support ADLINK Technology, Inc. provides a number of methods for contacting Technical Support listed below in Table A-1. Requests for support through the Ask an Expert are given the highest priority, and usually will be addressed within one working day. - Page 38 Address: 84 Genting Lane #07-02A, Cityneon Design Centre, Singapore 349584 Tel: +65-6844-2261 Fax: +65-6844-2263 Email: singapore@adlinktech.com ADLINK Technology Singapore Pte Ltd. (Indian Liaison Office) Address: No. 1357, "Anupama", Sri Aurobindo Marg, 9th Cross, JP Nagar Phase I, Bangalore - 560078, India Tel: +91-80-65605817 Fax: +91-80-22443548 Email: india@adlinktech.com...
-
Page 39: Appendix B I/O Interface Board Description
Figure B-1. I/O Interface Board Connectors (Top view) NOTE If you need more information concerning the I/O Interface Board than is provided in this Appendix, refer to the CoreModule 740 QuickDrive for a schematic, BOM, and AVL. CoreModule 740 Reference Manual... -
Page 40: I/O Interface Board Connectors And Headers
Interface Board. This appendix does not define industry-standard connectors on the board such as parallel, DB9 serial, PS2 mouse and keyboard, and USB. NOTE The CoreModule 740 does not support the Infrared header (J12) shown in Figure B-1. Table B-1 lists the signals and their descriptions for the Utility 1 interface which provides a shrouded 40-pin header with odd/even (1, 2) pin sequence. - Page 41 Serial Port 2 Transmit TTL – Places TTL TX signals on pin 3 of the Serial Port 2 (J4) when jumper (W1) on I/O Interface Board is set to (NF) pins 2-3. (NF = No function at the CoreModule 740.) USB PS0 J5-41 Power sense –...
-
Page 42: Table B-2. Utility 2 Interface Pin Signals (J2)
J5-79 Not Connected (External –5V input) Note: The shaded areas denote power or ground. NC = Not connected at the CoreModule 740. Table B-2 lists the signals and their descriptions for the Utility 2 interface which provides a shrouded 40-pin header with odd/even (1, 2) pin sequence. -
Page 43: Table B-3. Auxiliary Battery Interface Pin Signals (J10)
Parallel Select – This is a Status output signal from the printer. A High State indicates it is powered on. IR FIRM J5-52 IR Function Mode Select – Disabled (Terminated with 10k ohm resistor to ground on CoreModule 740.) J5-54 Not connected J5-56 Signal Ground... -
Page 44: Table B-4. Auxiliary Power Pin Signals (J11)
External -5 volt input (Not Connected) GND (NC) Ground (Not Connected) Note: The shaded areas denote power or ground. NC = Not Connected at the CoreModule 740. This table is only for reference. The CoreModule 740 has no function for this header. Reference Manual... -
Page 45: Index
..........32 console redirection low voltage limit ..........27 optional feature ..........28 serial console ..........28 Oops! jumper CoreModule 740 DB9 connector ..........28 Atom N450 CPU ..........4 Serial port 1 ...........28 block diagram ..........6 board thickness ..........11 power interface connector ........27... - Page 46 ..........19 source code examples ........29 serial ports ............5 weight ..............11 soldered SDRAM ..........5 splash screen (OEM Logo) ......32 USB interface ..........19 Utility 1 interface .......... 19 Watchdog Timer ..........6 Reference Manual CoreModule 740...
