Note:
(1) These signals are not connected on the board.
(2) These signals are pulled high on the board.
(3) These signals are pulled low on the board.
(4) By default, the VIO signals are set to +5V via
(5) J24 signals are connected to the CompactPCI J3

IDE Setting Jumper on the RTM

A CompactFlash (CF) socket is available on the RTM as a
Secondary IDE port. A 3-pin jumper (CN12) is used to set the CF
card as either master or slave device of the IDE channel.
Jumpers and Connectors
zero ohm resistors. Therefore, DO NOT apply
any "3.3V only" PMC module to the PMC
sockets.
connector. To use these signals, the RTM needs
to be custom designed for special purposes or
have a PIM connector available onboard. Please
contact ADLINK for details on customized RTM
applications.
CF card is a Master IDE
CF card is a Slave IDE device
(default factory setting)
device
47
