CM1-86DX2
PC/104 Single Board Computer
Technical Manual
P/N 50-1Z149-1030
Rev 4.00
Advance Technologies. Automate the World.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM1-86DX2 and is the answer not in the manual?

Questions and answers

Related Manuals for ADLINK Technology CM1-86DX2

Summary of Contents for ADLINK Technology CM1-86DX2

  • Page 1 CM1-86DX2 PC/104 Single Board Computer Technical Manual P/N 50-1Z149-1030 Rev 4.00 Advance Technologies. Automate the World.
  • Page 2 14971, if any. ADLINK may make changes to specifications and product descriptions at any time, without notice. Audience This manual provides reference only for computer design engineers, including but not limited to hardware and software designers and applications engineers. ADLINK Technology, Inc. assumes you are qualified to design and implement prototype computer equipment.

  • Page 3: Table Of Contents

    CM1-86DX2 Table of Contents 1 Introduction........................1 Overview ..........................1 Features..........................2 SoC ..........................2 Main Memory ........................2 Extension slots ......................... 2 Interfaces ........................2 Block Diagram........................3 Ordering Information ......................4 Specifications........................5 Electrical Specifications ....................5 Environmental Specifications ................... 5 Mechanical Specifications ....................
  • Page 4 100 Mbit Ethernet Connector (X7) .................24 Gbit Ethernet Connector (X6) ..................25 On-Board Power Supply ..................... 25 Power Connector (X25) ....................26 Real Time Clock Backup (BAT1) ...................26 IDE / SD / SATA Controller ....................27 IDE-Controller Features ....................27 SATA Connector (X11) ....................28 MicroSD Connector (X18) ....................28 Utility Header (X1) ......................29 External Battery ......................29...
  • Page 5 CM1-86DX2 RS-232 / RS-485 switching .................... 58 Watchdog0 Example ...................... 59 Watchdog1 Example ...................... 60 Analog Input Example ....................61 Memory Address Map......................64 I/O Address Map ......................... 65 PCI Configuration Registers ..................65 DMA Control Registers ....................65 Instruction Counter Registers ..................65 Timer/Counter Registers ....................

  • Page 7: Introduction

    System expansion is possible easily over the PC/104, Mini-PCI-Express and I²C bus connec- tors. The CM1-86DX2 is powered by a 5V-only supply and runs DOS, Windows XP/7 and Linux operating systems. The Vortex86-DX2 SoC has a simulated ACPI to support Windows 7 (though S3 or S4 modes are not supported.)

  • Page 8: Features

    1.2 Features Main Memory DMP Vortex86-DX2 @ max. 1GB DDR2 Memory Down   1 GHz Extension slots X86 Processor Core  1x MiniPCIe slot with mSATA  Floating point unit support  and USB capability (3.3 V I/O) Embedded I/D L1 Cache ...

  • Page 9: Block Diagram

    CM1-86DX2 1.3 Block Diagram CM1-86DX2 DS90C385A 512MB DDR2-400 Optional: LVDS 1GB DDR2-400 Memory Down LCD to LVDS Inverter (Backlight) i210IT PCIe Optional: JTAG Ethernet 8x A/D Input SATA Vortex86DX2 8x GPIO Option: SATA or mSATA 3x USB 2.0 RS232/485 2x COM...

  • Page 10: Ordering Information

    1.4 Ordering Information Table 1-1: CM1-86DX2 Models Order number Description CM1-86DX2 PC/104 CPU board with DMP Vortex86-DX2, including heat sink, and 1GByte of memory. Operating temp. range: -0°C … +60°C 702-0018-10 CPU clock: 1 GHz Memory clock: 333 MHz CM1-86DX2 PC/104 CPU board with DMP Vortex86-DX2, including heat sink, and 1GByte of memory.

  • Page 11: Specifications

    CM1-86DX2 1.5 Specifications Electrical Specifications Table 1-3: Electrical Specifications +5 V DC Supply voltage: +5 V standby (only needed for suspend mode) +12 V (only needed for LVDS display and expansion slots) < 10 ms Rise time: ± 5% Supply voltage tolerance: 1.6 A...

  • Page 12: Mechanical Specifications

    Table 1-6: HALT Parameters (Continued) The board was subject to vibration step stress with set Vibration Step Stress points from 5 grams to 45 grams @ 20°C and vibration increasing by 5 grams with 15 minute dwells at each level of 2Hz to 5000Hz bandwidth The board was subject to thermal cycles from -90°C to Combined Environment +85°C at an average rate of 60°C per minute combined...
  • Page 13 CM1-86DX2 85.62 85.62 81.10 81 10 62.92 6.76 7.12 17.36 17.36 44.07 62.87 62.87 Figure 1-2: Mechanical dimensions (top side) Introduction...
  • Page 14 Bottom 17.05 4.05 3.50 20.20 56.68 Figure 1-3: Mechanical dimensions (bottom side) Introduction...

  • Page 15: Getting Started

    CM1-86DX2 Getting Started 2.1 Header and Jumper Locations Table 2-1 on page 9 provides descriptions of the headers and connectors on the module. The header and connector locations are shown in Figure 2-1 and Figure 2-2. See Chapter 3 for the signal definitions of the headers and connectors presented in this table.

  • Page 16: Top

    Key: - Utility - PC/104 X2, X3, X16 - JTAG X4, X5 - COM X19 - Parallel - Gigabit Ethernet X23 - Audio - Fast Ethernet X25 - ATX Power - VGA C0 D0 CM1-86DX2_conn_top_b Figure 2-1: Header locations (top side) The yellow arrow heads next to the connectors in this illustration denote pin 1.

  • Page 17: Bottom

    CM1-86DX2 Bottom Figure 2-2: Header locations (bottom side) The yellow arrow heads next to the connectors in this illustration denote pin 1. Getting Started...

  • Page 18: Led Indicators

    2.2 LED Indicators The onboard LED indicators provide board status including error codes and Watchdog and Ethernet statuses. The MiniPCIe LEDs are located on bottom of the board, near the MiniPCIe connector. All other LEDs are located near the PC/104 connector on the top. Table 2-2: LED Name and Description Description STATUS (LED5, TOP)

  • Page 19: Hardware Setup

    Never connect or disconnect peripherals like HDDs, PCI, and ISA boards while the board's power supply is connected and switched on. Use the cable set provided by ADLINK Technology to connect the CM1-86DX2 to a VGA moni- tor. Connect either PS/2 or USB keyboard or mouse, respectively. Use the SATA cable to con- nect the hard disk.
  • Page 20 Getting Started...

  • Page 21: Module Description

    CM1-86DX2 Module Description 3.1 Processor and Chipset (SoC: System on a Chip) The Vortex86DX2 is a high performance and fully static 32-bit x86 processor with the compatibil- ity of running Windows, Linux, and most popular 32-bit Real-Time Operating Systems. It also integrates 32KB write through 4-way L1 cache, 256KB write-through/write-back 4-way L2 cache, PCIE bus at 2.5Gb/s, DDR2, ROM controller, ISA, I2C, SPI, IPC (Internal Peripheral...

  • Page 22: Processor Functional Blocks

    3.2 Processor functional blocks The processor part in the Vortex86DX2 consists of the following components: CPU Core  Northbridge  Southbridge  Graphics Controller for VGA or LVDS  Ethernet Controller  IDE / SD / SATA Controller  2x USB2.0 / USB1.1 Controller ...

  • Page 23: Features

    CM1-86DX2 2D Features Directly access data through M-Bus  High performance pipe-lined, one-cycle 64-bit 2D graphics engine  2D engine commands:  BitBlt Rectangle Fill  BitBlt Pattern Fill  BitBlt Rectangle Copy from Source to Destination  Support 256 Raster Operations ...

  • Page 24: Power Management Features

    Power Management Features Supports VESA Display Power Management Signaling (DPMS) compliant VGA monitor  for power management Supports direct I/O command to force graphics accelerator into standby/suspend-off state  Video Post-Processor Features Up/Down-Scaling  De-Interlace (Bob and Weave mode)  3:2 Sequence Pull-Down Detection ...

  • Page 25: Vga Header (X8)

    LVDS support can be configured within the BIOS. Using LVDS disables the VGA port on the CM1-86DX2. You can use a CRT or an LVDS panel only exclusively from each other. You can switch the video output at startup by pressing the “c”-Key for CRT-mode and the “t”-Key for LVDS-mode.

  • Page 26: Lvds Color Mapping

    LVDS Color Mapping Module Description...

  • Page 27: Lvds Header (X12)

    CM1-86DX2 LVDS Header (X12) Connector type: Hirose DF14 30-pin header Adapter cable: n/a Table 3-2: LVDS Header Signals (X12) Signal Signal VCC_LCD VCC_LCD LVDS_L3n LVDS_L3p LVDS_LCLKn LVDS_LCLKp LVDS_L2n LVDS_L2p LVDS_L1n LVDS_L1p LVDS_L0n LVDS_L0p n. c. n. c. n. c. n. c.

  • Page 28: Backlight Header (X13)

    Backlight Header (X13) Connector type: Hirose DF13 8-pin header Adapter cable: n/a Table 3-3: Backlight Header Signals (X13) Signal Signal +12 V +12 V +5 V +5 V VCC* *This voltage can be selected using the jumper "Backlight", shown on next table. The maximum current on all supply pins is 1A.

  • Page 29: Display Voltage Jumpers (X22)

    CM1-86DX2 Display Voltage Jumpers (X22) Jumper LVDS and Backlight Power Supply Connector type: DC6 pin header 2.00 mm Use a 2 mm jumper between 1-3 or 3-5 to select the backlight voltage. Use a 2 mm jumper between 2-4 or 4-6 to select the display voltage.

  • Page 30: Features Of The 10/100/1000 Mbit Controller

    Adapter cable: Article number 862-0005-10 Table 3-5: Fast Ethernet Header Signals (X7) Signal Signal ETH0_TXp ETH0_TXn ETH0_RXp ETH0_PE (Protection Earth for shielded Ethernet cables) ETH0_RXn USB2_p USB2_n +VCC_USB2 GND_USB2 *The CM1-86DX2-512 model does not offer the USB function on the X7 connector. Module Description...

  • Page 31: Gbit Ethernet Connector (X6)

    CM1-86DX2 Gbit Ethernet Connector (X6) Connector type: DC10 pin header 2.54 mm Adapter cable: Article number 862-0088-10 Table 3-6: Gbit Ethernet Header Signals (X6) Signal Signal ETH1_MX0n ETH1_MX0p ETH1_MX1n ETH1_MX1p ETH1_PE (Protection n. c. Earth for shielded Ethernet cables) ETH1_MX2n...

  • Page 32: Power Connector (X25)

    Power Connector (X25) Connector type: JST B15B-EH-A 15 pin Adapter cable: Article number 862-0044-10 Table 3-7: Power Connector Signals (X25) Signal (standard) Signal (5V only) +5V Standby PSON# PWROK +12V (only for PC104 slot and backlight power supply) +12V (only for PC104 slot and backlight power supply) -12V (only for PC104 slot) The default cable adapter supports the connection of 12V power supply.

  • Page 33: Ide / Sd / Sata Controller

    The integrated Serial ATA controller processes host commands and transfers data between the host and Serial ATA devices. With respect to the transfer rate, the integrated SATA controller supports first generation SATA (1.5 Gbit/s). The CM1-86DX2 provides one SATA connector (X11) for connecting a SATA disk drive or an optical SATA drive.

  • Page 34: Sata Connector (X11)

    SATA Connector (X11) Connector type: SATA Adapter cable: n/a Table 3-8: SATA Connector Signals (X11) Signal Data_TX+ Data_TX- Data_RX- Data_RX+ MicroSD Connector (X18) Connector type: MicroSD Table 3-9: MicroSD Connector Signals (X18) Signal Module Description...

  • Page 35: Utility Header (X1)

    CM1-86DX2 Utility Header (X1) The Utility header is shared with PS/2 mouse and keyboard, Speaker, Reset Switch, Power But- ton, and Battery. An adapter cable for the PS/2 devices is available. Connector type: IDC10 pin header 2.54 mm Adapter cable: Article number 862-0004-10...

  • Page 36: Power Button

    Power Button To power up/down the board, the signal Power Button must be pulled to GND. Table 3-12: Power Button Signals (X1) Signal Signal Speaker Mouse Clock Reset-In Mouse Data KB Data KB Clock +5V Standby Ext. Battery Power Button Reset Switch To reset the CPU using a reset switch, the Reset Switch signal must be pulled to GND.

  • Page 37: Usb 2.0 Ports

    USB port is controlled by the UHCI control- ler or by the EHCI controller. The CM1-86DX2 uses three of the four ports. They are available on two USB connectors, one providing two ports and one providing one port. USB 2.0 supports a USB keyboard running under MSDOS without special driver software.

  • Page 38: Usb 2.0 Port 2 Header (X7)

    DMA engines that are used to move data between system memory and the external codec. The CM1-86DX2 uses a codec from Realtek. The ALC886 is a high-performance 7.1+2 Channel High Definition Audio Codec. The following I/Os are used by the CM1-86DX2: Analog Input (All ADC support 44,1 kHz, 48 kHz, 96 kHz, and 192 kHz sampling rates) ...

  • Page 39: Audio Header (X23)

    CM1-86DX2 Audio Header (X23) Connector type: DC16 pin header, 2.54mm Adapter cable: Article number 862-0086-10 Table 3-17: Audio Header Signals (X23) Signal Signal LineOut_R LineOut_L Surround_R Surround_L Center GND_Audio GND_Audio LineIn_R LineIn_L MIC_R MIC_L S/P_DIF_IN S/P_DIF_OUT Module Description...

  • Page 40: Serial Ports

    The baud rates can be configured by the user application. Utility COM Ports The CM1-86DX2 provides some extra connectivity for an LV-TTL-UART interface (COM6.) More information on COM6 can be found in the User GPIO (X17) section and Analog-In (X21) about GPIOs, which are shared with COM6.

  • Page 41: Rs485/422 Termination

    RX+ and RX-, in the following illustration.) Additionally, positive/negative receive lines are pulled up/down with 10 kΩ to 5V/GND in order to protect the transceivers of the CM1-86DX2 from overvoltage. It is recommended to protect the ports of the external device in the same way.

  • Page 42: Lpt Interface (X19)

    3.10 LPT Interface (X19) The parallel port is located on an IC26 header. An adapter cable with standard DSUB-25 female connector is available. The parallel port is programmable in BIOS. Enter ADVANCED>CHIP- SET>Southbridge Configuration>Serial/Parallel Port Configuration for access to the following settings.

  • Page 43: Minipci-Express Interface (X10)

    CM1-86DX2 3.11 MiniPCI-Express Interface (X10) Connector type: MiniPCIe/MiniCard socket/mSATA socket Table 3-21: MiniPCIe Interface (X10) Signal Signal n.c. 3.3 V n.c. n.c. 1.5 V CLKREQ# n.c. n.c. PCIE1_CLK_n n.c. PCIE1_CLK_p n.c. n.c. Mechanical Key Reserved Reserved n.c. PERST# PCIE1_RX_n 3.3 V PCIE1_RX_p 1.5 V...

  • Page 44: Minipcie-Card-Mode Jumper Header (X20)

    MiniPCIe-Card-Mode Jumper Header (X20) The default setting is the automatic detection mode (shown below), where pins 3-4 are con- nected. To force mini card operation, pins 5-6 must be connected. The mSATA mode is forced by connecting pins 1-2 on the jumper block X20. Table 3-22: PCIe Mini Card Jumper Signals (X20) Signal Signal...

  • Page 45: Pc/104 Bus Connector (X14)

    CM1-86DX2 PC/104 Bus Connector (X14) Table 3-23: PC/104 Signals IOCHCK# RSTDRV IRQ9 DRQ2 -12V 0WS# +12V MEMCS16# SBHE# IOCHRDY IOCS16# LA23 SMEMW# IRQ10 LA22 SMEMR# IRQ11 LA21 IOW# IRQ12 LA20 IOR# IRQ15 LA19 DACK3# IRQ14 LA18 DRQ3 DACK0# LA17 DACK1#...

  • Page 46: Bmc Service Connector (X24)

    This can lead to application failures. 3.14 JTAG (X16) The CM1-86DX2 makes the JTAG port of the SoC accessible to the user. This JTAG is only sup- ported through DMP’s own JTAG tools. Currently, only BIOS recovery is possible through DMP’s JTAG tools.
  • Page 47 CM1-86DX2 The reference voltage is not intended to supply equipment other than low power equipment (Imax < 150 mA). The 8 analog channels are multiplexed through one conversion engine. So the sample rate is shared. This means the more channels that are active, the less the individual sample rate per channel will be.

  • Page 48: I2C Bus (X21)

    3.16 I2C Bus (X21) The CM1-86DX2 offers an I2C Bus for user applications. This Bus can be used to connect other devices which communicate over the I2C-Bus. The High-Level of this bus is 3.3V. Table 3-26: I2C Signals (X21) I2C0, X21 ADC_VCC (3.3 V)

  • Page 49: Using The Module

    Using the Module 4.1 BIOS The CM1-86DX2 features an AMI BIOS. The default settings provide a “ready to run” system, even without a BIOS setup backup battery. The BIOS is located in flash memory and can be easily updated with software under DOS.
  • Page 50 Advanced Settings screen The main screen of “Advanced Settings” provides settings for detailed CPU configuration, IDE controller configuration, Remote access configuration, USB controller configuration and ACPI configuration. The use of inappropriate values on any of the following advanced settings below may cause system to malfunction.
  • Page 51 CM1-86DX2 Recommended IDE settings for booting Windows: IDE Operate Mode [Native Mode] Standard IDE Compatible [Disabled] Recommended IDE settings for booting Linux: IDE Operate Mode [Native Mode] Standard IDE Compatible [Enabled] Using the Module...
  • Page 52 Using the Module...
  • Page 53 CM1-86DX2 PCIPnP Using the Module...
  • Page 54 Using the Module...
  • Page 55 CM1-86DX2 Boot screen If more than one drive is attached to the CM1-86DX2, you can select from the first “Boot Set- tings” screen the boot order the drives are scanned for a bootable OS image. The <Boot Settings Configuration> allows you to configure the boot behavior for a graphically enhanced BIOS SETUP UTILITY.
  • Page 56 Chipset screen Using the Module...
  • Page 57 CM1-86DX2 Using the Module...
  • Page 58 Using the Module...
  • Page 59 CM1-86DX2 Security screen Using the Module...

  • Page 60: Sema Functions

    Exit screen 4.2 SEMA functions The onboard Microcontroller implements power sequencing and SEMA functionality. The micro- controller communicates through the System Management Bus with the SoC. The following functions are available: Total operating hours counter  Counts the time the module has been run in minutes. On-time minutes counter ...

  • Page 61: Board Specific Sema Functions

    Use Main Current Function Main Current The BMC of the CM1-86DX2 implements a Current Monitor. The current can be read by calling the SEMA function “Get Main Current”. The function returns four 16-bit values divided in Hi-Byte (MSB) and Lo-Byte (LSB). These four values represent the last four currents drawn by the board.

  • Page 62: Watchdog Timer

    4.2V. 4.4 Temperature Sensors The CM1-86DX2 provides two temperature sensors. One is offered from the SoC and one from the BMC (managed by the SEMA). The Vortex86DX2 temperature sensor can be configured by programming the appropriate regis- ters.

  • Page 63: Programming Examples

    CM1-86DX2 4.5 Programming Examples The following programming examples are provided based on a Linux operating system. If other operating systems are used, some header files could be unnecessary or they may have different names. The "iopl()" function is a Linux specific function and defined inside the iopl.h header file. In Win- dows XP, a tool called "porttalk"...

  • Page 64: Rs-232 / Rs-485 Switching

    $data_reg Please note that this shell script example is provided for a system running a bash with Linux. It is using some proprietary software developed at ADLINK Technology, which is based on the code example given for GPIO programming. Using the Module...

  • Page 65: Watchdog0 Example

    CM1-86DX2 Example Watchdog0 #include <sys/io.h> #include <stdio.h> #define WDT0_INDEX 0x22 #define WDT0_DATA 0x23 int main() unsigned int wdog_time (0x20L * 0x500L); unsigned char trig = 0, wdog_en = 0, reset_cntr = 0; if (iopl(3) != 0) printf("IOPL error\n"); return 1;...

  • Page 66: Watchdog1 Example

    Watchdog1 Example #include <sys/io.h> #include <stdio.h> int main() unsigned int wdog_time (0x20L * 0x500L); unsigned char trig = 0, wdog_en = 0, reset_cntr = 0; if (iopl(3) != 0) printf("IOPL error\n"); return 1; //set time counter register: 0xac, 0xab, 0xaa outb((wdog_time >>...

  • Page 67: Analog Input Example

    CM1-86DX2 Analog Input Example ######################################################################## ######## FILE: sai.c AUTHOR: FS for LiPPERT Adlink Technology GmbH DESCRIPTIONActivates the ADC and reads the selected channel once PARAMETERS:channel # (0 ... 7) COMPILENAMEsai ######################################################################## ######## #include <sys/io.h> #include <stdio.h> #include <stdlib.h> #include <unistd.h>...
  • Page 68 *################################################################## ###### # 1. iopl(3) --> gain low level access and check input arguments of the command line ######################################################################## main(int argc, char ** argv) double capturedAdcValue = unsigned int capturedAdcData = 0, capturedAdcRaw = 0, onChipDeviceControl_value = 0, adc_control_register_value = 0; unsigned char capturedAdcChannel = 0, adcChannel = 0;...
  • Page 69 CM1-86DX2 ################################################################### ############# *################################################################## ############## # 3. set ADC Base Address, enable ADC IO Address Decode,configure ADC channel 7 as normal ADC input --> SB1_ADC_CONTROL_REG 3a. disable the 8051A access to the ADC ######################################################################## #########*/ adc_control_register_value = (1 << 20) + ADC_BASE_ADDR;...

  • Page 70: Memory Address Map

    *################################################################## ############## # 7. if ADC_STATUS bit 0 ==1 then read ADC_DATA as long as ADC_DATA[15:13] matches the selected ADC channel # 8. save ADC_DATA[10:0] & ADC_VAL_MASK as ADC data. ######################################################################## ########*/ capturedAdcRaw = inw( ADC_DATA capturedAdcChannel = capturedAdcRaw >> ) &...

  • Page 71: I/O Address Map

    CM1-86DX2 4.7 I/O Address Map The system chipset implements a number of registers in I/O address space. These registers occupy the following map in the I/O space: PCI Configuration Registers Table 4-4: PCI Configuration Registers Address range (hex) Description 0CFB - 0CF8 PCI Configuration Address Register 0CFF –...

  • Page 72: Interrupt Control Registers

    Interrupt Control Registers Table 4-8: Interrupt Control Registers Address range (hex) Description 0021 – 0020 Master Interrupt Control Registers 00A1 – 00A0 Slave Interrupt Control Registers 04D1 – 04D0 Interrupt Edge / Level Control Registers Keyboard/Mouse Control Registers Table 4-9: Keyboard/Mouse Control Registers Address range (hex) Description 0060...

  • Page 73: Watchdog1 Control Registers

    CM1-86DX2 Watchdog1 Control Registers Table 4-12: Watchdog1 Control Registers Address range (hex) Description 00A8 WDT1 Control Register 00A9 WDT1 Signal Select Control Register 00AA WDT1 Counter 0 Register 00AB WDT1 Counter 1 Register 00AC WDT1 Counter 2 Register 00AD WDT1 Status Register...

  • Page 74: Spare Registers

    Spare Registers Table 4-17: Spare Registers Address range (hex) Description 0080 Spare Register 0084 – 0086 Spare Register 0088 Spare Register 008C – 008F Spare Register 0480 Spare Register 0484 – 0486 Spare Register 0488 Spare Register 048C – 048F Spare Register 4.8 Interrupts Table 4-18: Interrupts...

  • Page 75: Dma Channels

    CM1-86DX2 4.9 DMA Channels Table 4-19: DMA Channels Data width System Resource 8 bits Available 8 bits Available 8 bits Available 8 bits Available Reserved, Cascade Channel 16 bits Available 16 bits Available 16 bits Available Using the Module...

  • Page 76: Contact Information
