GbE Connection Selection

The cPCI-6820 supports dual Ethernet connection for PICMG2.16
compliant backplanes and the RTM. While using the PICMG 2.16
compliant backplane, it is recommended that none of the GbE
ports on the rear panel be used. There are four mini switches that
control the GbE routing located on the bottom side (solder side) of
the RTM. Refer to the following information to choose either
PICMG 2.16 or rear panel Ethernet connections.
S3, S4: LAN1 Connecting Selection

Table 2-22: LAN1 Connection Selection

48
Switch S3
LAN 1
Connecting
Pin
S3-1
Connect to
S3-2
PICMG 2.16
S3-3
Backplane
S3-4
S3-1
Connect to
S3-2
Rear Panel
S3-3
(Default)
S3-4
Switch S4
State
Pin
State
OFF
S4-1
OFF
OFF
S4-2
OFF
OFF
S4-3
OFF
OFF
S4-4
OFF
ON
S4-1
ON
ON
S4-2
ON
ON
S4-3
ON
ON
S4-4
ON
