Key features
Large 1kB total buffering supporting concurrent Primary and
Secondary operation as well as traffic isolation.
Multiple output clock pins and nine pairs of REQ/GNT
signals support up to nine bus masters directly on
secondary bus without external clock buffer and bus arbiter.
5V tolerant I/O buffer, EEPROM support for extra register
control, Vital Product Data (VPD), 16 general purpose I/O
interface, and proven PME
D3 wakeup power management – one of the many
functions available in a single HB6 bridge.

BIOS

The cPCI-6810/6820 adopts the Award BIOS with a 4Mb flash
ROM implemented to load the BIOS. A boot block device is used
to allow recovery of the BIOS in the event of a catastrophic failure
(power failure during BIOS update). The BIOS supports the
following features:
CPU/memory speed auto-detection
DMI BIOS Support: Desktop Management Interface (DMI)
allows
information such as CPU type, CPU internal/external
frequencies, and memory size.
Green Function: APM/ACPI compliant Power management
via BIOS, activated through mouse/keyboard movement or
other wake-up events.
PCI Plug and Play support.
Intel pre-boot execution environment (PXE) support
PICMG2.1 CompactPCI hot-swap specification Rev. 1.0
support on CompactPCI I/O bus.
Introduction
users
to
download
system
hardware-level
7
