- Page 1 Flat Panel Transfer Board (FPTB) User's Manual Manual Revision: 2.00 Revision Date: August 9, 2012 Part Number: 50-1J040-1000...
- Page 2 Document History Revision Date Changes 2.00 2012/08/09 Initial Release FPTB User's Manual...
-
Page 3: Preface
This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of ADLINK Technology Inc. Trademark Information ®... -
Page 4: Table Of Contents
Table of Contents Preface ......................... 3 Introduction....................5 Overview....................... 5 Functional Block Diagram................5 Mechanical Drawing ..................6 Applications ....................7 Connectors and Jumpers ................9 Board Layout ....................9 Connector Pin Definitions ................10 Jumper Settings..................13 Getting Started..................14 Jumper Settings.................. -
Page 5: Introduction
The Flat Panel Transfer Board (FPTB) is intended for prototyping and verification of LVDS and TTL flat panel displays with COM Express systems. The FPTB is equipped with an LVDS-to-TTL converter to allow users to implement TTL displays with COM Express systems that support LVDS only. -
Page 6: Mechanical Drawing
1.3 Mechanical Drawing Dimensions in mm. FPTB User's Manual... -
Page 7: Applications
1.4 Applications The FPTB is intended for use in the following situations: • nanoX/Express-BASE → FPTB → Customer’s cable to TTL display: This configuration provides LVDS-to-TTL conversion and backlight control when using an ADLINK reference carrier board with a TTL display. User must provide the cable connection from the FPTB's TTL output and backlight control connectors to the TTL panel inputs. - Page 8 • Customer carrier (with LVDS output) → Customer’s cable to FPTB → FPTB → Customer’s cable to TTL panel: This configuration provides LVDS-to-TTL conversion and backlight control when using a customer carrier board with a TTL display. User must provide the cable connections from the customer carrier board LVDS output to the FPTB's LVDS input connector and from the FPTB's TTL output and backlight control connectors to the TTL panel inputs.
-
Page 9: Connectors And Jumpers
2 Connectors and Jumpers 2.1 Board Layout FPTB (Flat Panel Transfer Board) Connector and Jumper Locations Connector Description Power Connector LVDS Input Connector TTL Output Connector LVDS Output Connector Backlight Control Connector Backlight Voltage Jumper Panel Voltage Jumper LVDS/TTL Mode Selector Jumper Backlight Control Mode Jumper FPTB User's Manual... -
Page 10: Connector Pin Definitions
2.2 Connector Pin Definitions CN1: Power Connector (Floppy power connector) Signal +12V CN4: LVDS Input Connector (2x17 box header, 2.00 mm pitch) Signal Signal LVDS_CLK_A LVDS_DTA_A PNL_PWR PNL_PWR LVDS_A-N0 LVDS_A-P0 VDD_EN LVDS_A-N1 LVDS_A-P1 BL_EN_2 LVDS_A-P2 LVDS_A-N2 LVDS_ACLK _ N LVDS_ACLK _ P PNL_PWR LVDS_A-P3 LVDS_A-N3... - Page 11 CN5: TTL Output Connector (2x20 box header, 2.00 mm pitch) Signal Signal FCLK (HSYNC) (VSYNC) (DATA ENBLE) FPTB User's Manual...
- Page 12 CN6: LVDS Output Connector (2x17 box header, 2.00 mm pitch) Signal Signal LVDS_CLK_A LVDS_DTA_A PNL_PWR PNL_PWR LVDS_A-N0 LVDS_A-P0 VDD_EN LVDS_A-N1 LVDS_A-P1 BL_EN_2 LVDS_A-P2 LVDS_A-N2 LVDS_ACLK _ N LVDS_ACLK _ P PNL_PWR LVDS_A-P3 LVDS_A-N3 LVDS_B-N0 LVDS_B-P0 LVDS_B-N1 LVDS_B-P1 LVDS_B-N2 LVDS_B-P2 LVDS_BCLK _ P LVDS_BCLK _ N LVDS_B-P3 LVDS_B-N3...
-
Page 13: Jumper Settings
2.3 Jumper Settings JP1: Backlight Voltage Jumper Configuration 1 - 2 +12V 3 – 4 Reserved 5 – 6 +5V* JP2: Panel Voltage Jumper Configuration 1 - 2 +12V 3 – 4 Reserved 5 – 6 7 - 8 Reserved 9 - 10 +3.3V* JP4: LVDS/TTL Mode... -
Page 14: Getting Started
3 Getting Started The example instructions below describe how to use the FPTB to connect an ADLINK reference carrier board to a TTL display: In this configuration, the FPTB provides LVDS-to- TTL conversion and backlight control. The user must provide the cable connection from the FPTB's TTL output and backlight control connectors to the TTL panel inputs. -
Page 15: Lvds Input To Fptb
3.2 LVDS Input to FPTB Use the LVDS-to-LVDS cable that came with the FPTB to connect the LVDS output connector on the ADLINK carrier board (CN6 on nanoX-BASE) to the LVDS input connector on the FPTB (CN4). Plug the LVDS-to-LVDS cable into nanoX-BASE CN6 Plug the LVDS-to-LVDS cable connector into FPTB CN4 LVDS-to-LVDS cable FPTB User's Manual... -
Page 16: Ttl Output To Display Panel
3.3 TTL Output to Display Panel Make the appropriate cable to connect the TTL Output Connector (CN5) and Backlight Control Connector (CN8) on the FPTB to the target TTL display panel. 3.4 FPTB Power Connector Connect the Floppy Drive power connector of your power supply to the FPTB Power Connector (CN1). -
Page 17: Technical Support
