General Purpose LED definitions

Table 2-11: General Purpose LED definitions

Speaker connector on RTM

Table 2-12: Speaker Connector on RTM

Jumpers and Connectors
LED
Color Status
IDE Media
Red
Access
Power OK
Green
Hot swap-
Blue
pable status
Pin
1
2
3
4
Description
OFF
IDE idle
ON
IDE access
System is not power-
OFF
on or power failed
ON
Power ON
Board inserted and
OFF
power on
Board inserted but not
ON
power on yet
Signal Name
SPK-
GND
GND
SPK+
35
