2.3 Connectors Pin Assignment

Keyboard Connector

Note:

Mouse Connector

Note:
Jumpers and Connectors
Pin
1
KBDATA
2
3
4
5
KBCLK
6

Table 2-3: Keyboard Connector

Circular DIN keyboard connector is available on the
cPCI-6820 only. The cPCI-6810 does not support a
keyboard connector.
Pin
1
2
3
4
5
6

Table 2-4: Mouse Connector

Circular DIN mouse connector is available on the
cPCI-6820 only. The cPCI-6810 does not support a
mouse connector.
Signal
Function
Keyboard Data
NC
No Connect
GND
+5V
Keyboard Clock
NC
No connect
Signal
MSDATA
NC
GND
+5V
MSCLK
NC
Ground
Power
Function
Mouse Data
No Connect
Ground
Power
Mouse Clock
No Connect
31
