Graphic Display (available on cPCI-6820)
C&T 69000 VGA controller with integrated 2MB of memory.
VGA DB-15 connectors on front panel.
USB Interface
Supports up to four USB version 1.1 ports with integrated
USB host controller. Two USB ports (USB-0 and USB-1)
are BIOS configurable for front or rear access. Two USB
ports (USB-2 and USB-3) are rear access only.
USB ports provide 0.5A @ 5V power for peripheral devices
with over current protection.
IDE Ports
Bus master IDE controller supports two ultra ATA-100
interfaces.
Primary IDE is onboard with 44-pin IDE connector.
Both Primary and Secondary IDE ports are on J5 for RTM
extension.
Super I/O, WDT and Hardware Monitoring
Chipset: NS PC87417 low pin-count (LPC) Server I/O
controller.
Two 16C550 UART compatible RS-232 COM ports. COM1
on the front with RJ-45 type connector. COM2 is on the J3
and can be accessed on the RTM.
PS2 keyboard and mouse connector:
cPCI-6820: With 6-pin circular DIN connectors on both
the front board and RTM.
cPCI-6810: Connectors on RTM only.
Built-in W82782D monitoring CPU temperatures, FAN
speed, system temperature, V core, and DC voltages.
Watchdog timer: Programmable I/O port 10h-12h of bank 3
to configure watchdog timer, programmable 8-bit timer 1 -
255 minutes.
Real-Time Clock and Nonvolatile Memory: DS1287
compatible Real-Time Clock. 242 bytes CMOS RAM
16
