BIOS: ADLINK Enhanced Award / Phoenix BIOS
Support Intel® Pre-boot Execution Environment (PXE)
version 2.x, WFM 2.0. Include BIOS setup options and boot
from LAN
Support DMI / SMBIOS 2.3
CPU, memory operating frequency auto-detection
Bootable from USB storage devices including USB-Floppy,
USB-ZIP USB-CD-ROM and USB-HDD.
Optional OEM BIOS features
Customized OEM splash image / power on screen
Serial remote-console redirected to serial COM1 port
Note:
Due to BIOS segment limitations; enabling the remote
console function may occupy the same memory space
as other ROM mapping add-on or boot-up devices
such like Pre-boot Agent of Ethernet Boot ROM, SCSI
Boot ROM or add-on EIDE Boot ROM. It is
recommended that only one ROM-mapping add-on or
boot-up device be enable when enabling the remote
console function.
Gigabit Ethernet
Two Gigabit Ethernet (GbE) ports with Intel® 82546EB
Ethernet controller, based on local 66MHz/64-bit PCI bus.
Support 1000Base-T, 100Base-TX, and 10Base-T (IEEE
802.3, 802.3u, and 802.3ab).
IEEE802.3x compliant flow control, support auto-negotiation
and link setup.
GbE connection on PICMG 2.16 PSB or on RTM rear
access.
Speed and connection status LED on the front panel.
Introduction
15
