cPCI-R6820 RTM
The cPCI-R6820 is designed to provide additional I/O functionality
through rear I/O connectivity for the cPCI-6820 or cPCI-6810. The
cPCI-R6810 can be shipped with or without a storage device (IDE
HDD or CF card) depending on the options ordered. Please check
possible configurations with your dealer. As shipped, the product
package should contain the following items:
cPCI-R6820 RTM
Y-shape Keyboard/Mouse Combo cable
1.2 Features
cPCI-6810/6820 Features
PICMG 2.16 CompactPCI Packet Switching Backplane
(cPSB) Compliant
PICMG 2.9 System Management Bus Compliant
Standard 6U form factor, 1-slot (4HP) wide
Design for mobile Pentium-III/Tualatin CPU running at FSB
133MHz, single processor (cPCI-6810) or dual processors
(cPCI-6820)
Up to four 144-pin SO-DIMM sockets supporting up to 2GB
PC-133 SDRAM
64-bit/66MHz CompactPCI
Universal operation for both system and peripheral slots
Full hot-swap support
Onboard up to two 64-bit PMC module slot
Introduction
3
