3.3 HDD Installation on Main Board
A slim-type 2.5-inch HDD can be mounted to the cPCI-6810/6820
main board. If a HDD comes pre-installed in the cPCI-R6820
product package, this section may be skipped.
1. Remove the PMC Key-bolt of the PMC slot #1.
2. Screw the bolts on to the HDD; attach a 44-pin IDE
cable.
3. Install the assembly on to the board; tighten the four
screws from the bottom side of the main board to secure
the HDD in place.
4. Attach the other end of the 44-pin IDE cable to CN4 on
the board.
3.4 HDD Installation on RTM
A 2.5 inches HDD or Flash Disk can be installed on the RTM
directly. If a HDD comes pre-installed, please skip this section.
1. Attach the IDE cable to the HDD or Flash Disk
2. Put the HDD on component side of the RTM, align the
HDD's mounting holes with the holes on the PCB.
3. Tighten the four screws from the bottom side of the RTM
to secure the HDD in place.
4. Connect the IDE cable to the 44-pin connector CN4.
3.5 CF Installation on RTM
The CompactFlash Card (or called CF storage card) is widely
applied in digital consumer devices such as PDA's, Digital
Cameras, and MP3 players. Because of the CF anti-shock, anti-
vibration, better environment tolerance, low power consumption,
small form factor, and high reliability, it has been widely accepted
in mission critical embedded applications.
Getting Started
53
