S1, S2: LAN2 Connecting Selection

Table 2-23: LAN2 Connecting Selection

Setting Jumper on cPCI-6810/6820

A 3-pin jumper (JP1) is used to set the SBC as either "in normal
operation" or "forcing the SBC to SYSTEM mode".
Note:
When cPCI-6810/6820 in the Packet Switching
Backplane has no PCI bus, set JP1 as "1-2".
3
2
1
3
2
1
Jumpers and Connectors
LAN 2
Connecting
Connect to
PICMG 2.16
Backplane only
Connect to
Rear Panel
(Default)
Normal operation (Default setting)
Force cPCI-6810/6820 to SYSTEM mode
Switch S1
Switch S2
Pin
State
Pin
S1-1
OFF S2-1
S1-2
OFF S2-2
S1-3
OFF S2-3
S1-4
OFF S2-4
S1-1
ON
S2-1
S1-2
ON
S2-2
S1-3
ON
S2-3
S1-4
ON
S2-4
State
OFF
OFF
OFF
OFF
ON
ON
ON
ON
49
