Congatec conga-IA5 User Manual page 46

Pin Signal Pin
9 GND 10
11 REFCLK- 12
13 REFCLK+ 14
15 GND 16
17 Pull down resistor (1M) 18
19 N.C. 20
21 GND 22
23 PERn0 24
25 PERp0 26
27 GND 28
29 GND 30
31 PETn0 32
33 PETp0 34
35 GND 36
37 GND 38
39 +3.3Vaux 40
41 +3.3Vaux 42
43 mSATA_mPCIe_detect 44
45 CL_CLK 46
47 CL_DATA 48
49 CL_RST# 50
51 N.C. 52
53 GND 54
Connector Type
X9: PCIe mini card socket
Copyright © 2017 congatec AG
Signal
N.C.
N.C.
N.C.
N.C.
GND
W_DISABLE#
PERST#
+3.3Vaux
GND
+1.5V
SMB_CLK
SMB_DATA
GND
USB_D-
USB_D+
GND
N.C
N.C
N.C
+1.5V
GND
+3.3Vaux
GND
IA50m01 46/59
