Pin Signal
53
REFCLK-
55
REFCLK+
57
GND
59
N.C
61
N.C
63
N.C
65
N.C
67
RESET#
69
CONFIG_1
71
GND
73
GND
75
CONFIG_2
Connector Type
X12: M.2 type B slot (compatible with card size 3042 or 2242)
Note
Micro-SIM card slot (connector X10) is connected to the UIM Interface of the M.2 slot by default.
5.9
Display Interfaces
The conga-IA5 supports three simultaneous displays — two DP++ and an LVDS or eDP interface.
5.9.1
Display Port Interface DP++
The conga-IA5 SBC has two DP++ connectors (X26 and X27) located at the rear I/O panel. The DP++ connectors support DP, HDMI and DVI
displays. HDMI and DVI require an external passive cable adapter.
DP++ - Connectors X26/X27
Copyright © 2017 congatec AG
Pin Signal
54
PEWAKE#
56
N.C
58
N.C
60
N.C
62
N.C
64
N.C
66
N.C
68
SUSCLK
70
+3.3V
72
+3.3V
74
+3.3V
IA50m01
39/59
