CSP Dimensions for Atom™ Lidded Die Variants (PN: 052831 — conga-IA5/i-CSP)
21.2
75
19.75
Note
All measurements are in millimeters. Recommended maximum torque for cooling solution screws is 0.3 Nm. Mechanical system assembly
mounting shall follow the valid DIN/IS0 specifications.
Copyright © 2017 congatec AG
IA50m01
22/59
