1. Connect a Category 6 (or better) cable from your network switch or hub to
Ethernet port 0 (NET 0) on the rear of the chassis.
2. (Optional) Connect Category 6 (or better) cables from your network switch or
hub to the remaining Ethernet ports.
Related Information
"Available Connections" on page 61
■
"Cable the SP" on page 64
■
"Connect Other Data Cables" on page 65
■
"Identifying Ports" on page 65
■
"Rear Panel Components (Installation)" on page 15
■

Connect Other Data Cables

If your installation includes optional PCIe cards, USB devices, or alarms, make
the appropriate connections to those devices.
Gather the cables and equipment to make these connections, based on your server options:
PCIe cards — refer to PCIe device documentation
■
USB devices — see
■
Related Information
"Available Connections" on page 61
■
"Cable the SP" on page 64
■
"Cable the Ethernet Ports" on page 64
■
"Identifying Ports" on page 65
■
"Rear Panel Components (Installation)" on page 15
■

Identifying Ports

These topics provide connector descriptions and pinouts. See
(Installation)" on page 15
"SER MGT Port" on page 66
■
"USB Ports" on page 69
for the locations of the ports.
Connect Other Data Cables
"Rear Panel Components
Connecting Cables 65
