Depending on the DC power source, the positive terminal might be marked with a
Note -
positive (+) symbol, and the negative terminal might be marked with a minus (-) symbol.
5. Strip 1/2 in. (13 mm) of insulation from each of the wires.
Do not strip more than 1/2 in. (13 mm) from each wire. Doing so leaves uninsulated wire
exposed from the DC connector after the assembly is complete.
No. Description
1 1/2 in. (13 mm) maximum
6. Using a Phillips screwdriver, remove the terminal housing cover.
Assemble the DC Input Power Cords
Powering On the Server for the First Time 77
