No. Port Description
3 NET MGT A 10/100/1000BASE-T Ethernet connection through an
RJ-45 connector. This port supports remote connections to
the SP using the Oracle ILOM CLI and web interface.
By default, this port is configured to use DHCP or an IPv6
router to automatically obtain an IP address. Alternatively,
you can assign a static IP address to this port.
To use this port, it must have its network settings
configured. Once configured, you use the NET MGT port
IP address to login to the SP using a browser or secure
shell.
4 SER MGT A serial connection through an RJ-45 connector. This port
supports local connections to the SP and is limited to CLI
interaction with Oracle ILOM.
These are the default settings:
■ 8N1— eight data bits, no parity, one stop bit
■ 9600 baud
■ Disable hardware flow control (CTS/RTS)
■ Disable software flow control (XON/XOFF)
Related Information
"Cable the SP" on page 64
■
"Cable the Ethernet Ports" on page 64
■
"Connect Other Data Cables" on page 65
■
"Identifying Ports" on page 65
■
"Rear Panel Components (Installation)" on page 15
■

Connecting Data and Management Cables

These topics describe which ports you must cable before applying power to the server.
"Available Connections" on page 61
■
"Cable the SP" on page 64
■
"Cable the Ethernet Ports" on page 64
■
"Connect Other Data Cables" on page 65
■
Connecting Data and Management Cables
Needed
■ An Ethernet cable to connect to the NET MGT
port to your network.
■ An IP address for this port (required from DHCP
or a static address)
For pinout information, see "NET MGT
Port" on page 67.
If your environment does not provide DHCP
Note -
services, first use the SER MGT port to configure the
NET MGT port parameters.
■ A terminal device – can be a terminal, a
connection to a terminal server, or computer such
as a laptop running terminal emulation software.
■ A cable to connect the terminal device to the SER
MGT port.
For pinout information, see "SER MGT
Port" on page 66
Connecting Cables 63
