Oracle Netra SPARC S7-2 Installation Manual page 13

Component
Storage
Service processor
Ethernet ports
PCIe slots
PCIe internal HBA card
USB ports
eUSB flash drive
Indicators and switches
Power supplies
Cooling
Related Information
"Installation Task Overview" on page 11
■
"Front Panel Components (Installation)" on page 14
■
"Rear Panel Components (Installation)" on page 15
■
Netra SPARC S7-2 Server Service Manual
■
Description
■ Single Processor – 8 slots that support 16-GB, 32-GB, or 64-GB capacities.
■ Dual Processor – 16 slots (8 slots per CPU) that support 16-GB, 32-GB, or 64-GB capacities.
Note - The quantity and capacity of installed memory varies based on what was ordered.
■ Eight SFF slots for a maximum of eight SAS HDDs/SDDs
■ Four of the SFF slots can be used for NVMe SDDs
On the motherboard, an internal SP with cryptographic acceleration that supports industry standard
security ciphers. The SP runs Oracle ILOM firmware with provisions for:
■ Oracle ILOM 3.2.4
■ Serial management (RJ-45)
■ Network management (10/100/1000BASE-T Ethernet RJ-45)
Four 100/1000Mb/10Gb BASE-T Ethernet (RJ-45) with integrated link LEDs.
Six PCIe x8 Gen3 slots. Two are usable as x16 Gen3 slots, however, the electrical max remains x8, up
to 25 watts per card. All PCIe expansion slots support PCIe 3.0 / Gen3 (PCIe3) signaling levels.
(Optional) One internal SAS HBA PCIe controller card.
Two front 2.0 USB ports, and one rear 3.0 USB port.
One internal eUSB drive.
■ Power button switch
■ Locate button switch with integrated LED
■ System OK LED
■ System Fault LED
■ Alarm LEDs - Critical (Red), Major (Red), Minor (Amber), User (Amber)
■ Rear PS fault LED
Depending on the model, one of the following configurations:
■ 2 hot-swappable AC supplies (Oracle model A266)
■ 2 hot-swappable DC supplies (Oracle model D258)
Note - Mixing of AC and DC power supplies is not allowed.
Front-to-back forced air, with high efficiency active fan speed control.
Server Overview
Understanding the Server 13
