Automation VT Drive FC322 Design Guide
Warning Dual supply
How to add the MCB 105 option:
•
See mounting instructions in the beginning of section
Options and Accessories
•
The power to the live part connections on relay terminals must be disconnected.
•
Do not mix live parts (high voltage) with control signals (PELV).
•
Select the relay functions in par. 5-40
Function Relay
[6-8], par. 5-41
NB! (Index [6] is relay 7, index [7] is relay 8, and index [8] is relay 9)
MG.20.X1.22 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20783-Danfoss-131X8145-VLT-Automation-VT-Drive-VFD-FC322-460V-.5-HP.aspx
3 VLT Automation VT Drive Selection
On Delay, Relay
[6-8] and par. 5-42
Off Delay, Relay
[6-8].
®
