The FC protocol, also referred to as FC bus or Standard bus, is the Danfoss standard fieldbus. It defines an access technique according to the master-

slave principle for communications via a serial bus.

One master and a maximum of 126 slaves can be connected to the bus. The individual slaves are selected by the master via an address character in the

telegram. A slave itself can never transmit without first being requested to do so, and direct message transfer between the individual slaves is not possible.

Communications occur in the half-duplex mode.

The master function cannot be transferred to another node (single-master system).

The physical layer is RS-485, thus utilizing the RS-485 port built into the frequency converter. The FC protocol supports different telegram formats; a

short format of 8 bytes for process data, and a long format of 16 bytes that also includes a parameter channel. A third telegram format is used for texts.

7.2.1 VLT Automation VT Drive with Modbus RTU

The FC protocol provides access to the Control Word and Bus Reference of the frequency converter.

The Control Word allows the Modbus master to control several important functions of the frequency converter:

•

Start

•

Stop of the frequency converter in various ways:

Coast stop

Quick stop

DC Brake stop

Normal (ramp) stop

•

Reset after a fault trip

•

Run at a variety of preset speeds

•

Run in reverse

•

Change of the active set-up

•

Control of the two relays built into the frequency converter

The Bus Reference is commonly used for speed control. It is also possible to access the parameters, read their values, and where possible, write values

to them. This permits a range of control options, including controlling the setpoint of the frequency converter when its internal PID controller is used.
