Danfoss VLT AutomationVTDrive FC322 Design Manual page 119

4 How to Order
4.2.4 Ordering Numbers: Sine Wave Filter Modules, 200-500 VAC
Mains supply 3 x 200 to 500 V
Frequency converter size Minimum switching
200-240V 380-440V 440-500V frequency
PK25 PK37 PK37 5 kHz
PK37 PK55 PK55 5 kHz
PK75 PK75 5 kHz
PK55 P1K1 P1K1 5 kHz
P1K5 P1K5 5 kHz
4 PK75 P2K2 P2K2 5 kHz
P1K1 P3K0 P3K0 5 kHz
P1K5 5 kHz
P4K0 P4K0 5 kHz
P2K2 P5K5 P5K5 5 kHz
P3K0 P7K5 P7K5 5 kHz
P4K0 5 kHz
P5K5 P11K P11K 4 kHz
P7K5 P15K P15K 4 kHz
P18K P18K 4 kHz
P11K P22K P22K 4 kHz
P15K P30K P30K 3 kHz
P18K P37K P37K 3 kHz
P22K P45K P55K 3 kHz
P30K P55K P75K 3 kHz
P37K P75K P90K 3 kHz
P45K P90K P110 3 kHz
P110 P132 3 kHz
P132 P160 3 kHz
P160 P200 3 kHz
P200 P250 3 kHz
P250 P315 3 kHz
P315 P355 2 kHz
P355 P400 2 kHz
P400 P450 2 kHz
P450 P500 2 kHz
P500 P560 2 kHz
P560 P630 2 kHz
P630 P710 2 kHz
NB!
When using Sine-wave filters, the switching frequency should comply with filter specifications in par. 14-01
118
MG.20.X1.22 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20783-Danfoss-131X8145-VLT-Automation-VT-Drive-VFD-FC322-460V-.5-HP.aspx
Automation VT Drive FC322 Design Guide
Maximum output Rated filter current at
Part No. IP20 Part No. IP00
frequency 50Hz
120 Hz 130B2439 130B2404 2.5 A
120 Hz 130B2439 130B2404 2.5 A
120 Hz 130B2439 130B2404 2.5 A
120 Hz 130B2441 130B2406 4.5 A
120 Hz 130B2441 130B2406 4.5 A
120 Hz 130B2443 130B2408 8 A
120 Hz 130B2443 130B2408 8 A
120 Hz 130B2443 130B2408 8 A
120 Hz 130B2444 130B2409 10 A
120 Hz 130B2446 130B2411 17 A
120 Hz 130B2446 130B2411 17 A
120 Hz 130B2446 130B2411 17 A
60 Hz 130B2447 130B2412 24 A
60 Hz 130B2448 130B2413 38 A
60 Hz 130B2448 130B2413 38 A
60 Hz 130B2307 130B2281 48 A
60 Hz 130B2308 130B2282 62 A
60 Hz 130B2309 130B2283 75 A
60 Hz 130B2310 130B2284 115 A
60 Hz 130B2310 130B2284 115 A
60 Hz 130B2311 130B2285 180 A
60 Hz 130B2311 130B2285 180 A
60 Hz 130B2312 130B2286 260 A
60 Hz 130B2312 130B2286 260 A
60 Hz 130B2313 130B2287 410 A
60 Hz 130B2313 130B2287 410 A
60 Hz 130B2314 130B2288 480 A
60 Hz 130B2315 130B2289 660 A
60 Hz 130B2315 130B2289 660 A
60 Hz 130B2316 130B2290 750 A
60 Hz 130B2317 130B2291 880 A
60 Hz 130B2317 130B2291 880 A
60 Hz 130B2318 130B2292 1200 A
60 Hz 130B2318 130B2292 1200 A
Switching Frequency .
®
