Danfoss VLT AutomationVTDrive FC322 Design Manual page 70

Automation VT Drive FC322 Design Guide
FC322, P37KT2
Cable Mains Rise time
length [m] voltage [V] [μsec]
30 240 0.300
100 240 0.536
150 240 0.776
FC322, P45KT2
Cable Mains Rise time
length [m] voltage [V] [μsec]
30 240 0.300
100 240 0.536
150 240 0.776
FC322, P1K5T4
Cable Mains Rise time
length [m] voltage [V] [μsec]
5 690 0.640
50 985 0.470
150 1045 0.760
FC322, P4K0T4
Cable Mains Rise time
length [m] voltage [V] [μsec]
5 400 0.172
50 400 0.310
150 400 0.370
FC322, P7K5T4
Cable Mains Rise time
length [m] voltage [V] [μsec]
5 500 0.04755
50 500 0.207
150 500 0.6742
FC322, P11KT4
Cable Mains Rise time
length [m] voltage [V] [μsec]
15 480 0.192
100 480 0.612
150 480 0.512
FC322, P15KT4
Cable Mains Rise time
length [m] voltage [V] [μsec]
36 480 0.396
100 480 0.844
150 480 0.696
MG.20.X1.22 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20783-Danfoss-131X8145-VLT-Automation-VT-Drive-VFD-FC322-460V-.5-HP.aspx
3 VLT Automation VT Drive Selection
Vpeak dU/dt
[kV] [kV/μsec]
0.598 1.594
0.566 0.844
0.546 0.562
Vpeak dU/dt
[kV] [kV/μsec]
0.598 1.594
0.566 0.844
0.546 0.562
Vpeak dU/dt
[kV] [kV/μsec]
0.690 0.862
0.985
1.045 0.947
Vpeak dU/dt
[kV] [kV/μsec]
0.890 4.156
2.564
1.190 1.770
Vpeak dU/dt
[kV] [kV/μsec]
0.739 8.035
4.548
1.030 2.828
Vpeak dU/dt
[kV] [kV/μsec]
1.300 5.416
1.300 1.699
1.290 2.015
Vpeak dU/dt
[kV] [kV/μsec]
1.210 2.444
1.230 1.165
1.160 1.333
®
is a registered Danfoss trademark
3
69
