Automation VT Drive FC322 Design Guide
5.3.8 Access to Control Terminals
All terminals to the control cables are located underneath the terminal cover on the front of the frequency converter. Remove the terminal cover by means
of a screwdriver (see illustration).
Illustration 5.17: Frame sizes A1, A2, A3,B3, B4, C3 and C4
5.3.9 Control Terminals
Drawing reference numbers:
1.
10 pole plug digital I/O.
2.
3 pole plug RS485 Bus.
3.
6 pole analog I/O.
4.
USB Connection.
MG.20.X1.22 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20783-Danfoss-131X8145-VLT-Automation-VT-Drive-VFD-FC322-460V-.5-HP.aspx
5 How to Install
Illustration 5.18: Frame sizes A5, B1, B2, C1 and C2
Illustration 5.19: Control terminals (all enclosures)
®
is a registered Danfoss trademark
5
151
