Size/Type Bussmann PN* Rating
P450 170M7081 1600 A, 700 V
P500 170M7081 1600 A, 700 V
P560 170M7082 2000 A, 700 V
P630 170M7082 2000 A, 700 V
P710 170M7083 2500 A, 700 V
P800 170M7083 2500 A, 700 V
Table 5.11: Frame size F, Line fuses, 380-500 V
Size/Type Bussmann PN*
P450 170M8611 1100 A, 1000 V
P500 170M8611 1100 A, 1000 V
P560 170M6467
P630 170M6467
P710 170M8611 1100 A, 1000 V
P800 170M6467
Table 5.12: Frame size F, Inverter module DC Link Fuses, 380-500 V
*170M fuses from Bussmann shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and amperage
may be substituted for external use
**Any minimum 500 V UL listed fuse with associated current rating may be used to meet UL requirements.
525-690 V, frame sizes D, E and F
Size/Type Bussmann PN* Rating
P355 170M4017 700 A, 700 V
P400 170M4017 700 A, 700 V
P500 170M6013 900 A, 700 V
P560 170M6013 900 A, 700 V
Table 5.13: Frame size E, 525-690 V
Size/Type Bussmann PN* Rating
P630 170M7081 1600 A, 700 V
P710 170M7081 1600 A, 700 V
P800 170M7081 1600 A, 700 V
P900 170M7081 1600 A, 700 V
P1M0 170M7082 2000 A, 700 V
Table 5.14: Frame size F, Line fuses, 525-690 V
Size/Type Bussmann PN*
P630 170M8611 1100 A, 1000 V
P710 170M8611 1100 A, 1000 V
P800 170M8611 1100 A, 1000 V
P900 170M8611 1100 A, 1000 V
P1M0 170M8611 1100 A, 1000 V
Table 5.15: Frame size F, Inverter module DC Link Fuses, 525-690 V
*170M fuses from Bussmann shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and amperage
may be substituted for external use.
MG.20.X1.22 - VLT
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20783-Danfoss-131X8145-VLT-Automation-VT-Drive-VFD-FC322-460V-.5-HP.aspx
5 How to Install
Siba Internal Bussmann Option
20 695 32.1600 170M7082
20 695 32.1600 170M7082
20 695 32.2000 170M7082
20 695 32.2000 170M7082
20 695 32.2500 170M7083
20 695 32.2500 170M7083
Rating Siba
20 781 32.1000
20 781 32.1000
1400 A, 700 V 20 681 32.1400
1400 A, 700 V 20 681 32.1400
20 781 32.1000
1400 A, 700 V 20 681 32.1400
Ferraz Siba
6.9URD31D08A0700 20 610 32.700
6.9URD31D08A0700 20 610 32.700
6.9URD33D08A0900 20 630 32.900
6.9URD33D08A0900 20 630 32.900
Siba Internal Bussmann Option
20 695 32.1600 170M7082
20 695 32.1600 170M7082
20 695 32.1600 170M7082
20 695 32.1600 170M7082
20 695 32.2000 170M7082
Rating Siba
20 781 32. 1000
20 781 32. 1000
20 781 32. 1000
20 781 32. 1000
20 781 32. 1000
®
