Chapter 2

Environmental Specifications

Table 2-6 provides the most efficient operating and storage condition ranges required for this module.

Table 2-6. Environmental Requirements

Parameter
Temperature
Standard
Extended (Optional)
Storage
Humidity
Operating
Non-operating

Thermal/Cooling Requirements

The CPU is the primary source of heat on the board. The CoreModule 920 is designed to operate at the
maximum speed of the CPU and requires an active heatsink for extended temperatures (optional). A passive
heatsink is available (optional) and allows maximum speed operation within the Standard temperature range.
The passive heatsink will allow operation in the Extended temperature range if the CPU speed is locked at
800MHz. To lock the CPU speed at 800MHz, use the Power Consumption setting field in the CPU/PPM
Configuration submenu of the
measurements of the cooling assemblies.
NOTE All heights are given in inches.
20
Conditions
–20° to +70° C (–4° to +158° F)
–40° to +85° C (–40° to +185° F)
–55° to +85° C (–67° to +185° F)
5% to 90% relative humidity, non-condensing
5% to 95% relative humidity, non-condensing
"Advanced BIOS Setup Screen" on page
Passive Heat Sink
0.38
Active
Heat Sink
2.53
1.45
Heat Spreader
0.22

Figure 2-10. Stack Heights of Cooling Assemblies

Reference Manual
40. See Figure 2-10
Fan
Product Overview
for height
CoreModule 920
