Chapter 4
•
PCH-FW Configuration
ME FW Version

ME Firmware Mode

ME Firmware Type

ME Firmware SKU

•
Intel(R)Anti-Theft Technology Configuration
Intel(R) Anti-Theft Technology [Disabled; Enabled]

Intel(R) Anti-Theft Technology Rec [X]

Enter Intel(R) AT Suspend Mode [Disabled]

•
USB Configuration
USB Devices:

X Keyboard, 2 Hubs
Legacy USB Support [Enabled; Disabled; Auto]

EHCI Hand-off [Disabled; Enabled]

USB hardware delays and time-outs:

• USB transfer time-out [1 sec; 5 sec; 10 sec; 20 sec]
• Device reset time-out [10 sec; 20 sec; 30 sec; 40 sec]
• Device power-up delay [Auto; Manual]
•
ADT 7490 H/W Monitor
ADT 7490 Pc Health Status

• Module temperature
• ADT7490 temperature
• CPU temperature (By PECI)
• Vtt
• Vccp
• Vcc
• +5V
• +12V
•
F81216 Super IO Configuration
Super IO Chip

F81216 Serial Port 1 Configuration

• Serial Port
• Device Settings
• Change Settings
42
X.X.XX.XXXX
Normal Mode
Full Sku Firmware
XMB
: +XX C
: +XX C
: +XX C
: +X.XXX V
: +X.XXX V
: +X.XXX V
: +X.XXX V
: +XX.XXX V
Fintek F81216
[Disabled; Enabled]
IO=3F8h; IRQ=4;
[Auto;
IO=3E8h; IRQ=7;
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E0h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F0h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12]
