Chapter 3
Supports DVD-Audio and Audio Return channel
Provides one 19-pin, standard HDMI micro connector
PEG (PCI Express Graphics):
Supports external high-performance PCI Express graphics cards
Supports general-purpose PCI Express devices
Supports theoretical bandwidth of up to 8GT/s
Provides PCIe Gen3 compliance
Table 3-10
defines the signals of the VGA interface, which consists of 10 pins, 2 rows, odd/even, (1, 2) with
0.079" (2mm) pitch.

Table 3-10. VGA Interface Pin Signal Descriptions (J17)

Pin #
Signal
1
VSYNC
2
HSYNC
3
DDC-CLK
4
RED
5
DDC-DATA
6
GREEN
7
VDD5V0
8
BLUE
9
GND
10
GND
Note: The shaded table cells denote power or ground.
Table 3-11
lists the pin signals of the LVDS video header, which provides 20 pins, 2 rows, odd/even pin
sequence (1, 2) with 0.079" (2mm) pitch.
Table 3-11. LVDS Video Interface Pin Signals (J23)
Pin #
Signal
1
+12V
2
VCC_LVDS_CONN
3
GND
4
GND
5
LVDSA_CLK_P
6
LVDSA_CLK_N
7
LVDSA_DAT3_P
8
LVDSA_DAT3_N
9
LVDSA_DAT2_P
10
LVDSA_DAT2_N
11
LVDSA_DAT1_P
12
LVDSA_DAT1_N
30
Description
Vertical Sync – This signal is used for the digital vertical sync (polarity is
programmable) 2.5V output to the VGA display.
Horizontal Sync – This signal is used for the digital horizontal sync
(polarity is programmable) or "sync interval" 2.5V output to the VGA
display
Display Control Clock
Red – This is the Red analog output signal to the VGA display.
Display Control Data
Green – This is the Green analog output signal to the VGA display.
Power – This is the +5 volts +/- 5% power signal from the external power
interface.
Blue – This is the Blue analog output signal to the VGA display.
Ground
Ground
Description
+12 volts for flat panel and backlight
JP3 determines LVDS voltage (+3.3V or +5V)
Ground
Ground
LVDS A Clock Positive
LVDS A Clock Negative
LVDS A DATA Positive Line 3
LVDS A DATA Negative Line 3
LVDS A DATA Positive Line 2
LVDS A DATA Negative Line 2
LVDS A DATA Positive Line 1
LVDS A DATA Negative Line 1
