Chapter 2
NOTE
All dimensions are given in inches. Pin 1 is shown as a black pin (square or
round) on vertical headers. Black dots on right-angle headers indicate pin 2.

Power Specifications

Table 2-5 provides the power requirements for the CoreModule 730.

Table 2-5. Power Supply Requirements

Parameter
Input Type
In-rush Current
(Maximum)
Idle Power
BIT* Current
(Typical)
Operating configurations:
•
In-rush operating configuration includes CRT video and 2GB DDR2 RAM.
•
Idle operating configuration includes the In-rush configuration as well as on-board 128MB Compact
Flash, one IDE hard drive, one mouse, and one keyboard.
•
*BIT = Burn-In-Test operating configuration includes Idle configuration as well as one USB Compact
Flash reader with 64MB Compact Flash and one USB CD-ROM drive.

Environmental Specifications

Table 2-6 provides the operating and storage condition ranges required for this module.

Table 2-6. Environmental Requirements

Parameter
Temperature
Operating
Extended (Optional)
Storage
Humidity
Operating
Non-operating

Thermal/Cooling Requirements

The CPU is the primary source of heat on the board. The CoreModule 730 CPU is designed to operate at
maximum speed and requires a heatsink (provided).
CoreModule 730
Characteristics for 1.6GHz CPU
Regulated DC voltages
6.69A (33.45W)
0.17A (0.85W)
0.60A (3.00W)
Conditions
–20° to +70° C (–4° to +158° F)
–40° to +85° C (–40° to +185° F)
–55° to +85° C (–67° to +185° F)
5% to 90% relative humidity, non-condensing
5% to 95% relative humidity, non-condensing
Reference Manual
Product Overview
13
