Chapter 1

Purpose of this Manual

This manual is for designers of systems based on the CoreModule
manual contains information that permits designers to create an embedded system based on specific design
requirements.
Information provided in this reference manual includes:
•
Product Overview
•
Hardware Specifications
•
BIOS Setup information
•
Technical Support Contact Information
Information not provided in this reference manual includes:
•
Detailed chip specifications (refer to the References section of this chapter)
•
Internal component operation
•
Internal registers or signal operations
•
Bus or signal timing for industry-standard busses and signals
•
Pin-signal definitions for industry-standard interfaces

References

The following list of references may help you successfully complete your custom design.
Industry Standard Specifications
•
PCI/104-Express Specification, Revision 2.0, February, 2011
Web site: http://www.pc104.org/pci104_Express_specs.php
•
PCI-104 Specification
Web site: http://www.pc104.org/pci_104_specs.php
•
PCI Express Specification, Revision 2.0, January, 2007
Specification (for members):
•
PCI Specification, Revision 2.3, March 29, 2002
Web site: http://www.pcisig.com
•
LPC Specification Version 1.1
Web site: http://www.intel.com/design/chipsets/industry/lpc.htm
•
USB Specification Version 2.0
Web site: http://www.usb.org/developers
•
SATA Specification Version 3.0
Web site: http://www.sata-io.org/
•
Ethernet IEEE802.3 Specifications
Web site: http://standards.ieee.org/about/get/802/802.3.html
CoreModule 920
About This Manual
http://www.pcisig.com/specifications/pciexpress/base2/#b21
Reference Manual
®
920 Single Board Computer (SBC). This
1
