ADLINK Technology CoreModule 920 Reference Manual page 18

Chapter 2
Table 2-1. Major Component Descriptions and Functions (Continued)
RS-232 Transceiver
(U20)
RS-232 Transceiver
(U21)
Solid State Drive
[SSD] - SATA (U22)
- on bottom side [see
Figure 2-4])
Hardware Monitor
(U27) [on bottom
side; see Figure 2-4]
SPI Flash (U28)
HDMI Level Shifter
(U48)
EEPROM, DDR3
(U66 - on bottom
side [see Figure 2-4])
EEPROM,
PCIe-to-PCI Bridge
(U67 - on bottom
side [see Figure 2-4])
Transformer -
Gigabit Ethernet
(T1)
Transformer -
Gigabit Ethernet
(T2)
12
Texas TR3253EIRSMR
Instruments
Texas TR3253EIRSMR
Instruments
Greenliant GLS85LS1008P
ON ADT7490-D
Semicondu
ctor
Winbond W25Q64BVSSIG
ST STHDLS101TQTR
Microelectr
onics
Atmel AT24C02C
Atmel AT24C02C
Wurth 7490200110
Elektronik
Wurth 7490200110
Elektronik
Reference Manual
Product Overview
Transceiver for Transmits and
Serial 1 RS-232 receives RS-232
signals signals for
COM1
Transceiver for Transmits and
Serial 2 RS-232 receives RS-232
signals signals for
COM2
Industrial-grade Provides solid
soldered solid-state state storage
storage module through SATA
port 2
Remote Voltage and Provides system
Temperature thermal
Monitor and Fan protection
Controller
Serial Peripheral Stores BIOS in
Interface Flash Flash Memory
Memory chip (for
firmware)
HDMI level-shift IC Converts HDMI
for HDMI video differential input
from the PCH to
TMDS
differential
output for the
HDMI interface
Two-Wire Serial Provides storage
EEPROM for SPD for System
(Serial Presence Memory
Detect) configuration
data
Two-Wire Serial Stores PCIe-to-
EEPROM for PCIe- PCI bridge
to-PCI Bridge configuration
data
Gigabit Ethernet Provides
Magnetics electrical
isolation for
Gigabit Ethernet
PHY transceiver
(GLAN1)
Gigabit Ethernet Provides
Magnetics electrical
isolation for
Gigabit Ethernet
controller
(GLAN2)
CoreModule 920
